APC by Schneider Electric WSTS200A-SPL1 Emergency SET - Spare Part KIT

Overview

The APC by Schneider Electric WSTS200A-SPL1 is a spare part kit for their Static Transfer Switch (STS) system, designed to provide seamless power continuity for critical loads. This kit is intended for installations requiring a specific replacement component or for stocking critical spares to minimize downtime. It supports a wide range of input and output voltages, including 208V, 480V, and 600V 3-phase, making it adaptable to various industrial and data center environments. The WSTS200A-SPL1 facilitates hardwired connections for up to two zones, ensuring robust power distribution.

Compatibility

This spare part kit is specifically designed for APC by Schneider Electric's 200A Static Transfer Switch (STS) systems. It is not a standalone unit and requires integration with a compatible STS main chassis. The kit is engineered to interface with systems supporting 208V, 480V, and 600V 3-phase power configurations.

Installation Notes

Installation requires qualified electrical personnel familiar with 3-phase power systems and the specific APC STS product line. The kit includes provisions for hardwiring 4-wire (3PH + G) and 5-wire (3PH + N + G) configurations for one zone each. The unit has a maximum line current rating of 200A and is designed for front mounting. Environmental operating conditions include a relative humidity range of 5-90% and an operating altitude of up to 3333 ft. Storage conditions allow for temperatures between -40°F and 158°F (-40°C to 70°C).

What's in the Box

• 1x Installation guide
• 1x User Manual
