Brand:
Digital Watchdog
MPN:
DWC-XSWA08BI
Image Sensor:
48MP 1/1.8” Star-Light
Total Pixels:
3856(H) x 2200(V)
Active Pixels:
3840(H) x 2160(V)
Minimum Illumination Color:
0.15 lux
Minimum Illumination B/W:
0 lux
S/N Ratio:
50dB
Video Output:
CVBS 1.0V p-p (75Ω)
Focal Length:
2.3mm, F2.8
Lens Type:
Fixed lens
Horizontal Field of View:
175°
Vertical Field of View:
80°
IR Distance:
100ft
Audio Input:
1 line input (1.0Vms, 3K ohm)
Microphone:
Built-in
Audio Output:
1 output
Audio Compression:
G.711 ulaw
Alarm Input:
1 input
Alarm Output:
1 output
Event Trigger:
Motion, network loss, temperature, illegal login, schedule, sensor
AI Analytics:
Object and people detection, classification, tracking
Shutter Mode:
Auto, manual, anti-flicker, slow shutter
Shutter Speed:
1/15 ~ 1/32000
Slow Shutter:
1/2, 1/3, 1/5, 1/6, 1/7.5, 1/10
Auto Gain Control:
Auto
Day and Night:
Auto, day (color), night (B/W)
3D Noise Reduction:
Smart DNR™ 3D-DNR
Wide Dynamic Range:
True WDR, 120dB
Alarm Notifications:
Email, FTP, alarm output, SD card
Memory Slot:
Micro SD/SDHC/SDxC class 10
LAN:
1000Base-T (1Gbps)
Video Compression:
H.265, H.264, MJPEG
Max Resolution:
3840x2160
Frame Rate:
Up to 30fps
Video Bitrate:
100Kbps ~ 25Mbps
Bitrate Control:
CBR/VBR
Streaming Capability:
Triple Streaming
IP Protocol:
IPv4
Network Protocols:
TCP/IP, UDP, AutoIP, RTP, RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMP
Security:
HTTPS (TLS), IP filtering, 802.1x, digest authentication
Web Viewer OS:
Windows 7, 8, 10
Web Viewer Browser:
Edge, Chrome, Firefox, Safari
Operating Temperature:
-4°F ~ 122°F (-20°C ~ 50°C)
Operating Humidity:
10–90% RH (non-condensing)
IK Rating:
IK10
Other Certifications:
CE, FCC, RoHS, UL, NDAA, TAA
Power Requirement:
DC12V, PoE
Power Consumption DC12V:
max 9.6W, 800mA
Power Consumption PoE:
max 11.6W, 42mA
Material:
Aluminum die-casting bullet housing
Dimensions:
6.29” x 4.86” x 3.54” (160 x 123.5 x 90mm)
Weight:
2.2 lbs (1 kg)
Warranty:
5 year
