Code Blue 71013 LS1000-SEC Axis Cam Phone CC
The Code Blue 71013 is an audio paging accessory designed to extend the LS1000 VoIP speakerphone platform into integrated surveillance and two-way communication deployments. This component bridges visual alerting (Axis camera integration) with synchronized audio broadcast capability, enabling security teams to issue coordinated announcements across facility zones without requiring separate paging infrastructure. The 71013 is suited for access control checkpoints, facility entrances, parking structures, and perimeter stations where unified camera-plus-audio presence is operationally critical.
Key Features
- Audio Paging Integration: 12–24V DC powered audio amplification for synchronized broadcast messaging with LS1000 VoIP system. Eliminates need for standalone paging amplifiers at camera-equipped entry points.
- Axis Camera Compatibility: Designed to integrate with Axis IP cameras paired to the LS1000-SEC faceplate assembly, enabling unified video + audio alerting from a single mounted unit.
- Multi-Mount Flexibility: Supports wall surface, pole-mounted, recessed cavity, and vertical rack installation orientations. Adapt to existing LS1000 enclosure and facility architecture without redesign.
- LS1000 Series Native Integration: Drop-in replacement or supplemental component for Code Blue LS1000 audio paging and VoIP speakerphone infrastructure. Works with standard LS1000 faceplates and wiring harnesses.
- Modular Audio Architecture: Separates audio amplification from IP codec and camera interface, simplifying troubleshooting and allowing independent audio path replacement or upgrade.
- Facility Zone Deployment: Compact form factor and multiple mounting options enable distributed audio coverage across parking lots, loading docks, and outdoor secured areas without central amp bottleneck.
The 71013 is part of the LS1000 ecosystem—a purpose-built platform for converged security and emergency communication at access points. Unlike generic paging amplifiers, this unit is tuned to the LS1000 speakerphone's impedance and audio characteristics, ensuring reliable synchronized messaging when paired with Axis camera feeds.
Installation orientation flexibility (wall, pole, recess, rack) addresses real-world facility constraints. A parking structure perimeter may require pole-mounted units; a data center or server room may use recessed mounting in existing cable trays. The 71013 adapts to each scenario without requiring multiple SKUs. Verify your existing LS1000 frame variant and faceplate revision before ordering—the LS1000 family includes multiple enclosure options documented in the Code Blue parts cross-reference guide.
Audio input routing and amplifier gain settings are managed through the parent LS1000 speakerphone unit. No independent configuration interface exists on the 71013 itself; all audio paging logic flows through the LS1000 control plane. This keeps deployment straightforward but also means troubleshooting audio faults requires access to the LS1000 unit's firmware and network settings.
Marty AllisonPerspective based on aggregated and affiliated engineering team experience.
In our experience, the 71013 fills a specific gap in converged security deployments where integrators are already committed to the LS1000 VoIP platform and need to add synchronized audio paging without introducing a separate amplifier or third-party codec. We've seen it installed at secure facility entrances, vehicle gate houses, and outdoor checkpoints where both video confirmation and voice instruction from the control room are non-negotiable. The multi-mount flexibility is genuinely useful—one job had us deploying units on a facility perimeter fence line (pole-mounted), at a badge-reader vestibule (recessed in the wall frame), and in an equipment rack inside the security office (vertical mounting). That adaptability reduced our need to stock multiple variants or get creative with custom brackets. That said, the 71013 is tightly coupled to the LS1000 ecosystem. It's not a standalone paging amp you can pair with arbitrary IP cameras or non-Code Blue VoIP platforms. If your integrator team is already standardized on Axis cameras, Genetec VMS, and independent paging vendors, the 71013 adds complexity rather than value. It's a consolidation play for shops that have chosen Code Blue as their emergency communication spine.
Technical Highlights:
- 12–24V DC Power Input: Works with standard facility DC supplies and battery backup systems. Low voltage minimizes NEC conduit requirements compared to 120V line-powered paging amps; simplifies mixed outdoor/indoor cabling.
- Audio Impedance & Gain Tuning: Pre-tuned to LS1000 speakerphone output levels; no separate amp gain pot adjustment needed. Reduces installation commissioning time and eliminates feedback loops from incorrect impedance matching.
- Faceplate & Harness Modularity: Swappable with standard LS1000 component harnesses. If audio circuitry fails, you swap the 71013 module rather than the entire LS1000 unit—shorter downtime, lower replacement cost.
- Four Mounting Modes in One SKU: Wall, pole, recess, and rack mounting all enabled by single hardware design. Reduces parts inventory overhead for integrators managing multi-site deployments.
- Synchronized Broadcast with Axis Cameras: Audio paging is triggered by the same control logic that activates Axis camera recording and alerting. A visitor buzzes a door, camera streams to VMS, and audio prompt plays simultaneously—no separate coordination between systems.
Deployment Considerations:
- LS1000 Firmware Dependency: Audio paging functionality is controlled entirely by the parent LS1000 unit's firmware and network configuration. If you need to audit or change paging behavior (zones, priority, repeat intervals), you're editing LS1000 settings, not the 71013. Plan VoIP network testing and LS1000 commissioning time accordingly.
- Verify Faceplate & Enclosure Revision Before Ordering: The LS1000 family includes multiple faceplate and enclosure variants. The 71013 is a replacement component, not a retrofit upgrade. Confirm your existing LS1000 frame SKU and faceplate revision number with Code Blue before placing the order to avoid incompatibility delays.
- Outdoor Pole-Mount Durability: Pole mounting works, but ensure your facility provides weather-sealed backbox and cable routing. The 71013 itself is not rated for direct rain exposure; enclosure IP rating depends on the mounting frame you pair it with.
- Audio Path Troubleshooting: If paging audio fails, isolate between the 71013 module (hardware fault), the LS1000 speakerphone (firmware/config issue), or the upstream VoIP call signaling. Standard troubleshooting requires LS1000 diagnostic access, not independent unit testing.
- Integration Lock-In Risk: Choosing the 71013 commits the site to the Code Blue LS1000 ecosystem for emergency communication. If you later want to migrate to a different VoIP platform or paging vendor, ripping out the 71013 also means replacing the entire LS1000 unit. Evaluate long-term facility standards before deployment.
The 71013 is the right choice for integrators who are already standardized on Code Blue's LS1000 platform and need to add synchronized audio broadcast to Axis camera checkpoints without introducing external paging equipment. If your baseline is LS1000 + Axis integration, the 71013 is a straightforward, modular addition that simplifies the control plane. For shops building mixed-vendor systems or looking for standalone paging flexibility, a traditional audio amplifier paired with a separate VoIP codec will likely offer more long-term adaptability. See the Code Blue catalog for additional LS1000 components and emergency communication accessories.
