Lifesafety Power FPO150-2D8E6S 150W Single Voltage Power Supply
Overview
The FPO150-2D8E6S is a 150-watt single-voltage (120 VAC input) power distribution unit with 16 auxiliary outputs, designed for small-to-medium surveillance, access control, and low-voltage system installations. This supply bridges the gap between consumer-grade wall-mount units and full rack-mount chassis — it provides adequate power for distributed camera feeds, door locks, and control modules without requiring separate sub-panels at each location. The 120 VAC input matches standard building power in North America; the 16 outputs let you branch power to multiple devices from one hardwired source, reducing installation complexity.
Compatibility
The FPO150-2D8E6S works with any low-voltage surveillance, access control, or alarm system that operates on 12 VDC or 24 VDC (verify your system's voltage requirement before deployment). Compatible with PoE-injected network cameras, wireless access points, door controllers, strike locks, and credential readers. Commonly integrated into Honeywell, Johnson Controls, Nortek, and generic IP-based security ecosystems. Confirm your devices' voltage and current draw against the unit's output specifications before final installation.
Installation Notes
The FPO150-2D8E6S requires hardwired 120 VAC mains connection (consult local electrical code for circuit breaker sizing and conduit requirements). Mount in a dry, accessible location away from moisture and temperature extremes. Do not daisy-chain multiple supplies without load balancing — each output group has a maximum current rating. Ensure all auxiliary outputs are properly terminated and fused per the system design. Keep wire runs under 500 feet to minimize voltage drop to remote devices; if longer runs are necessary, use larger-gauge conductors or step up to a supply located closer to the load.
