Lenovo 4B27A09313 SR850 V2 2-CPU Socket and 24 DIMM Configuration

Overview

The Lenovo 4B27A09313 is a configuration option for the ThinkSystem SR850 V2 2U rack server, enabling a 2-CPU socket topology with 24 DIMM slots. This part code unlocks a specific hardware layout within the SR850 V2 chassis — relevant when provisioning a dual-processor memory-dense build rather than a full 4-socket configuration. The feature code designation for 4B27A09313 is BAVY, which appears in Lenovo's CTO ordering system for SR850 V2 configurations across machine types 7D31, 7D32, and 7D33. Specify this option during system configuration to establish the correct motherboard and socket arrangement before selecting processors, DIMMs, and storage components.

Compatibility

Designed exclusively for the Lenovo ThinkSystem SR850 V2 platform across three machine types: 7D31 (1-year warranty baseline), 7D32 (3-year warranty standard configurations including SAP HANA-adjacent builds), and 7D33 (SAP HANA configurations with 3-year warranty). The SR850 V2 uses the Intel C621A 'Lewisburg' chipset on the Cedar Island platform. Compatible processors in the 2-socket configuration include Intel Xeon Gold 5318H (18-core), 5320H (20-core), 6330H (24-core), and Platinum 8354H (18-core) among others. In 2-socket mode, the 24 DIMM slots support standard DDR4 ECC memory with SDDC and ADDDC protection for x4-based DIMMs, plus memory mirroring — giving you hardware-level redundancy without a separate controller. Persistent memory modules are also supported; keep ambient temperature at or below 27°C when PMem is installed to avoid thermal throttling. Storage in this configuration can reach up to 737.28TB using 24x 30.72TB 2.5-inch SAS/SATA SSDs, or mixed NVMe/SSD/HDD topologies are supported. Up to 2x single-wide GPUs can be added. Hot-swap drives, fans, and power supplies are all supported in this chassis layout.

Installation Notes

This is a CTO (Configure-To-Order) option specified at the time of system ordering — it is not a field-installable standalone component. Confirm chassis compatibility using feature code BAVY within Lenovo's configuration tooling before ordering. The SR850 V2 chassis (feature codes BCPH or BN19) must be selected alongside this socket configuration. No internal optical or tape drive bays are present in the SR850 V2, so plan external or network-based media access accordingly.

Expert Analysis
Specifications
Weight: 60.00 lb
Unspsc Code: 43211600
Components: Specification
Machine Types: 7D31 - 1-year warranty 7D32 - 3-year warranty 7D33 - SAP HANA configurations with 3-year warranty
Form Factor: 2U rack.
Chipset: Intel C621A "Lewisburg" chipset, part of the platform codenamed "Cedar Island" (CDS)
Persistent Memory: To avoid triggering throttle, it is advised that the ambient temperature is kept 27°C or lower when persistent memory modules are installed.
Memory Protection: ECC, SDDC (for x4-based memory DIMMs), ADDDC (for x4-based memory DIMMs), memory mirroring.
Maximum Internal Storage: 737.28TB using 24x 30.72TB 2.5-inch SAS/SATA SSDs 368.64TB using 24x 15.36TB 2.5-inch NVMe SSDs 57.6TB using 24x 2.4TB 2.5-inch HDDs Mix of NVMe/SSDs/HDDs supported.
Optical Drive Bays: No internal optical drive.
Tape Drive Bays: No internal backup drive.
Gpu Support: Supports up to 2x single-wide GPUs
Cooling: Six N+1 redundant hot-swap 60 mm fans (all six standard). One additional fan integrated in each power supply.
Video: G200 graphics with 16 MB memory with 2D hardware accelerator, integrated into the XClarity Controller. Maximum resolution is 1920x1200 32bpp at 60Hz.
Hot-Swap Parts: Drives, fans and power supplies.
Operating Systems Supported: Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi. See the Operating system support section for specifics.
Dimensions: Width: 445 mm (17.5 inches), height: 87 mm (3.4 inches), depth: 825 mm (32.5 inches). See Physical and electrical specifications for details.
Machine Type/Model General Purpose: Machine Type/Model for AI and HPC
7D32Cto1Ww: 7D32CTOLWW
7D31Cto1Ww: 7D31CTOLWW
7D33Cto1Ww: 7D33CTOLWW
Feature Code: Description
Bn19: ThinkSystem SR850 V2 Chassis v2
Bcph: ThinkSystem SR850 V2 Chassis
Model: Description
7D32A00Vap: 2x Gold 5318H 18C 150W 2.5GHz
7D32A00Wap: 2x Gold 5320H 20C 150W 2.4GHz
7D32A00Xap: 2x Gold 6330H 24C 150W 2.0GHz
7D32A00Yap: 2x Platinum 8354H 18C 205W 3.1GHz
7D32A011Ea: 2x Gold 5318H 18C 150W 2.5GHz
7D32A012Ea: 4x Gold 5318H 18C 150W 2.5GHz
7D32A00Zea: 4x Gold 6330H 24C 150W 2.0GHz
7D32A010Ea: 4x Platinum 8360H 24C 225W 3.0GHz
4B27A09313: BAVY
4Xg7A63392: BB9K
4Xg7A63391: BB9J
4Xg7A63389: BB9F
4Xg7A63486: BD8D
4Xg7A63390: BB9G
4Xg7A63388: BB9E
4Xg7A63386: BB9C
4Xg7A63387: BB9D
4Xg7A63394: BB9M
4Xg7A63385: BB9B
4Xg7A63505: BDXU
4Xg7A63384: BB9A
4Xg7A63485: BD8E
4Xg7A63383: BB99
4Xg7A63484: BD8F
Cpu Model: Cores / threads
5318H: 18 / 36
5320H: 20 / 40
6328H: 16 / 32
6328Hl: 16 / 32
6330H: 24 / 48
6348H: 24 / 48
8353H: 18 / 36
8354H: 18 / 36
8356H: 8 / 16
8360H: 24 / 48
8360Hl: 24 / 48
8376H: 28 / 56
8376Hl: 28 / 56
8380H: 28 / 56
8380Hl: 28 / 56
Bfyb: Operating mode selection for: "Maximum Performance Mode"
Bfyc: Operating mode selection for: "Minimal Power Mode"
Bfyd: Operating mode selection for: "Efficiency Favoring Power Savings Mode"
Bfye: Operating mode selection for: "Efficiency - Favoring Performance Mode"
4X77A08632: B963
4X77A08633: B964
4X77A08634: B965
4X77A08635: B966
4X77A08636: BA62
4Zc7A08727: B4Y3
4Zc7A08732: B98B
4Zc7A08734: B98A
4Zc7A08736: BB8T
Total Installed Per Processor: App Direct mode ratio†
16Gb: 32GB
960 Gb: 1 : 4
1.125 Tb: 1 : 2
1.5 Tb: 1 : 1
1.875 Tb: 1 : 4
2.25 Tb: 1 : 2
3 Tb: 1 : 1
3.75 Tb: 1 : 4
4.5 Tb: 1 : 2
B8Lu: ThinkSystem 2U 8x2.5" SAS/SATA Backplane
B8Lm: ThinkSystem 2U/4U 8x2.5" AnyBay Backplane
Bcqm: ThinkSystem 2U/4U 8x2.5" NVMe Backplane
Cfg: SAS/SATA
Starting Config: Target config
S/S: Any
1X 430/530-8I (8: 3x 430/530-8i (8)
1X Raid/Hba 16I (16: 1x RAID/HBA 8i (8) + 1x RAID/HBA 16i (16)
1X Raid/Hba 8I (8: 1x RAID/HBA 8i (8) + 1x RAID/HBA 16i (16)
Ob Sata (8: OB SATA (8) + 1x RAID/HBA 16i (16)
Ob Nvme (16: OB NVMe (16) + 2x 1610-8P (4+4)
4X97A59822: ThinkSystem SR860 V2/SR850 V2 Switch/Retimer NVMe Cable Accessories Kit 4x SBB7A16999 - PCIe Cable: Re-Timer Card to BP (Slimline x8 to 1x MICO x8), 970mm
4Xh7A99569: ThinkSystem 2.5" 1x1 HDD Filler by 8 units (contains 8x single drive-bay fillers)
4C57A15020: B8P2
4C57A15021: B8P3
Cto Only: B8LE
4C57A15017: Upgrade only*
00D9998: A5U1
00D9999: AS6C
00Fp648: A5U1
00Fp649: AS6C
7S0A007Fww: S874
7S0A008Vww: SDJR
7S0A008Www: SDJS
7S0A008Xww: SDJT
7S0A007Hww: S876
7S0A008Yww: SDJU
7S0A008Zww: SDJV
7S0A0090Ww: SDJW
7S0A007Kww: S878
7S0A0091Ww: SDJX
7S0A0092Ww: SDJY
7S0A0093Ww: SDJZ
7S0A007Mww: S87A
7S0A0094Ww: SDK0
7S0A0095Ww: SDK1
7S0A0096Ww: SDK2
7S0A007Pww: S87C
7S0A0097Ww: SDK3
7S0A0098Ww: SDK4
7S0A0099Ww: SDK5
None: B9X7
4L47A39164: B96G
7Y37A01082: AUNG
4Y37A72482: BJHK
7Y37A01084: AUNJ
4Y37A72483: BJHL
4Y37A09727: BFY5
4Y37A09721: B31E
4Y37A72485: BJHN
4Y37A78834: BMFT
4Y37A09728: B8NY
Cto Only: BQ8S
4Y37A09729: B8NW
4Y37A78835: BNAX
7Y37A01085: AUNK
4Y37A78600: BM35
4Y37A09730: B8NZ
4Y37A09733: B8P8
7Y37A01088: AUNL
4Y37A72480: BJHH
7Y37A01089: AUNM
4Y37A72481: BJHJ
4Y37A78601: BM51
4Y37A78602: BM50
4C57A65446: B98C
7Xb7A00021: AULV
7Xb7A00022: AULW
7Xb7A00023: AULX
7Xb7A00024: AULY
7Xb7A00025: AULZ
7Xb7A00027: AUM1
7Xb7A00028: AUM2
4Xb7A83970: BRG7
7Xb7A00034: AUM6
7Xb7A00035: AUM7
7Xb7A00031: AUM5
7Xb7A00033: B0YX
4Xb7A84038: BRG8
7Xb7A00036: AUUE
7Xb7A00037: AUUJ
4Xb7A80340: BNW8
4Xb7A80341: BNW9
4Xb7A80342: BNW6
4Xb7A80343: BP3K
4Xb7A80318: BNWC
4Xb7A80319: BNWE
4Xb7A80320: BNWF
4Xb7A80321: BP3E
4Xb7A80322: BP3J
4Xb7A80323: BP3D
4Xb7A83214: BR10
4Xb7A83215: BR0Z
4Xb7A83216: BR0Y
4Xb7A83217: BR0X
4Xb7A70006: BG07
4Xb7A70005: BG06
4Xb7A70007: BFZZ
4Xb7A70004: BG05
4Xb7A70003: BG04
4Xb7A17062: B8HU
4Xb7A17063: B8J4
4Xb7A17065: B8JA
4Xb7A38175: B91A
4Xb7A38176: B91B
4Xb7A17054: B91C
4Xb7A17055: B91D
4Xb7A17056: BC4R
4Xb7A90884: BYM2
