i-PRO M-WM-JB-MINI Wall Mount with Junction Box
Overview
The M-WM-JB-MINI is a wall-mount bracket with integrated junction box designed for secure installation of i-PRO fixed dome cameras on exterior and interior walls. The aluminum-alloy construction and integrated junction box solve two deployment problems: stable camera positioning on masonry, concrete, or steel surfaces, and organized cable routing without exposed conduit. The compact form factor (9.1" × 4.9" × 5.1") sits flush against most wall types while providing backplate clearance to prevent infrared light from reflecting off the wall back into the lens — a real issue when dealing with dome cameras and glare-prone mounting surfaces.
Compatibility
Compatible with i-PRO fixed dome cameras including M-46-FW-V2, M-46-F-V2, M-45-FW-V2, M-26-FW, M-44-FW-L, and M-84-FW-L. Verify your camera model against this list before ordering — the mounting interface is application-specific. The junction box supports standard RJ-45, power, and auxiliary cabling typical of IP dome installations, eliminating need for separate external conduit or surface-mounted cable management.
Installation Notes
Aluminum alloy construction resists corrosion and UV degradation in outdoor environments down to concrete, masonry, steel, and wood-frame anchor points. At 1.94 lbs, the bracket distributes camera weight evenly to prevent lens drift over thermal cycling. Powder-coated white finish minimizes visible mounting hardware. Confirm wall anchor compatibility with your structural surface type before drilling — concrete requires concrete anchors; steel studs require machine screws; wood requires lag bolts. No torque specifications are provided in the technical data; consult your camera's installation guide for recommended bracket bolt torque.
