i-PRO M-5360 5MP Fisheye Camera
The i-PRO M-5360 is a compact 5MP fisheye camera engineered for single-camera wide-area surveillance in indoor and semi-outdoor environments. Delivering 360-degree panoramic coverage with a 1.4mm lens, the M-5360 combines high-resolution imaging, advanced compression technologies, and built-in infrared illumination to provide flexible, cost-effective coverage for security integrator installations requiring ONVIF-compatible deployment.
Key Features
- 360-Degree Panoramic Capture: 1.4mm F2.0 lens delivers complete hemispheric coverage with flexible 3-axis angle adjustment for ceiling or wall mounting
- 5MP Resolution at 30 fps: 2592 x 1944 pixel capture with tri-stream encoding supporting 1080p and 720p sub-streams for bandwidth optimization
- Advanced Compression: H.265, H.264, and MJPEG support with configurable bitrate (128 Kbps to 16 Mbps) and up to 8 regions of interest (ROI) for targeted encoding efficiency
- Infrared Night Vision: Built-in IR illumination with automatic day/night switching via IR-cut filter; 0.01 lux minimum illumination in color mode; effective range up to 10 meters
- True WDR Processing: 120dB wide dynamic range ensures balanced exposure in mixed lighting conditions typical of hallways, atriums, and retail spaces
- IP66 Weatherproofing & IK10 Vandal Resistance: Sealed against dust and moisture spray with robust protection against physical impact
- PoE Power & Ethernet Connectivity: Single cable deployment simplifies installation while microSD card support enables local storage backup
- ONVIF Compatibility: Seamless integration with major VMS platforms and third-party security systems
Technical Specifications
- Resolution: 5MP (2592 x 1944)
- Frame Rate: 30 fps
- Lens: 1.4mm fisheye
- Video Compression: H.265, H.264, MJPEG
- IP Rating: IP66
- Vandal Rating: IK10
- Power: PoE (Power over Ethernet)
- Connectivity: Ethernet (ONVIF)
- Storage: microSD card support
- Weight: 0.79 lbs
- Security: HTTPS encryption
Ideal Applications
The M-5360 is well-suited for retail environments, shopping centers, parking structures, office atriums, and transportation hubs where single-camera panoramic coverage reduces deployment complexity and cost. The combination of 5MP resolution, WDR processing, and IR illumination delivers reliable surveillance across varying lighting conditions, while ONVIF compatibility ensures integration flexibility for system integrators supporting diverse VMS ecosystems.
Marty AllisonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The i-PRO M-5360 addresses a specific market need: organizations requiring true 360-degree coverage without multi-camera installations. The 1.4mm fisheye lens provides genuine hemispheric view angles that simplify mounting and reduce blind spots—critical for open-plan interiors. H.265 compression support reduces bandwidth and storage requirements by up to 50% compared to H.264, while tri-stream capability allows operators to optimize quality for primary monitoring (5MP at 30 fps) while maintaining efficient sub-streams for archival.
The 120dB WDR and 0.01 lux night vision ensure usable imagery in challenging mixed-lighting scenarios common in retail and transportation settings. IP66/IK10 ratings, while marketed as "semi-outdoor," position this camera primarily for sheltered interior use; true outdoor deployment requires protective housing. PoE simplicity and microSD backup reduce infrastructure costs and improve resilience.
For integrators standardized on ONVIF platforms, the M-5360 provides a solid single-camera wide-angle option that balances resolution, compression efficiency, and deployment flexibility.
