i-PRO M-49-V-V2 4MP Motorized Varifocal Bullet Camera
The i-PRO M-49-V-V2 is a 4MP outdoor varifocal bullet camera designed for deployments where focal length adjustment must happen remotely—without a technician returning to the site. The motorized 2.8–12mm lens (4.3× zoom) captures 2688×1520 resolution at 30 fps and delivers a field-of-view range from 86.3° (wide) to 35.2° (telephoto). This flexibility cuts deployment time on installations where exact lens selection is uncertain at commissioning, and it lets operators pull back for perimeter coverage or zoom in for facial identification and license-plate detail—all from the VMS interface.
Key Features
- Motorized Varifocal Lens (2.8–12mm, 4.3× Zoom): Auto-focus motor adjusts both focal length and focus point remotely via ONVIF or native protocol commands. Eliminates the labor cost and site revisits required for fixed-lens swaps. Wide-angle mode covers parking lots and building perimeters; telephoto mode isolates subject details from distance. Once the M-49-V-V2 is installed, lens changes happen on-screen.
- 4MP Native Resolution (2688×1520 @ 30 fps): Delivers detection-range performance of approximately 63m in wide mode and 270m in telephoto mode, according to standard DORI metrics. A single camera can often replace multiple fixed-lens units in scenarios where zoom flexibility improves evidence quality and reduces blind spots.
- Extended IR-LED Night Vision (850nm, 40m Range): Built-in infrared illuminators reach 131 feet without external spotlights. Supports 0 lux monochrome operation with IR active, plus 0.003 lux color performance at F1.6 with auto-gain. Eliminates separate IR floodlights on perimeter or lot deployments, reducing wiring complexity and power consumption.
- 120dB Wide Dynamic Range (WDR): Handles backlit scenes, reflective surfaces, and mixed lighting—sun through windows, artificial overhead, and shadows in the same frame. Ensures usable identification detail in high-contrast moments (parking garage entries, loading docks with bay doors open, building lobbies). No blooming or shadow crush.
- H.265, H.264, and MJPEG Codec Support: H.265 (HEVC) cuts storage and bandwidth roughly in half compared to H.264 on 24/7 recording—a direct cost reduction across multi-camera deployments. Configure main stream (2688×1520, 2560×1440, 2304×1296, 1920×1080, 1280×720) and sub-stream (1280×720, 720×576, 640×360) independently to balance archival quality, storage footprint, and remote-viewing performance on constrained network links.
- IP67 Outdoor Enclosure (Graphene and Metal): Rated for direct rain, dust, and environmental contamination. Operating range –30°C to +60°C (–22°F to +140°F) supports northern winters and southern heat without performance drift. Skip this model only if full submersion (IP68/69K) is required—otherwise, IP67 handles normal outdoor exposure reliably.
- PoE Power (IEEE 802.3af, 9.6W Max): Draws less than 10 watts, so it operates safely on standard 802.3af switches without power-budget oversubscription. Alternative 12V DC input via coaxial jack provides flexibility in air-gapped or legacy installations. No external power supply, no separate circuit breaker, no clutter at the camera head.
- Built-in Microphone and Line Audio Input: 35kΩ line input (2V p-p) with G.711U/G.711A codec support enables audio event detection (glass break, alarm sounds, shouting) and two-way voice communication through ONVIF-compliant VMS platforms. Streamlines sites where audio forensics or emergency intercom functionality is required without adding a separate device.
- On-Board Analytics (ROI and Masking): Cross-line detection, intrusion detection (human body recognition), motion detection, tampering alarm, and audio event detection run on the camera's processor. Configure up to 8 regions of interest (ROI) and 4 privacy-masking zones to focus processing on active areas, reduce false alarms, and respect privacy boundaries without server-side complexity or licensing overhead.
Integration and Compatibility
The M-49-V-V2 supports ONVIF Profile S, T, and G, ensuring compatibility with mainstream network video recorders and VMS platforms that recognize the motorized lens control protocol. Native i-PRO integration is available through Panasonic's own i-PRO IP camera ecosystem. The built-in microphone and line-input jack integrate with any VMS that passes audio streams via RTP or G.711. For PoE switch planning, account for the 9.6W draw per camera; a single 802.3af switch with 10–15 port capacity can safely provision 5–8 of these units without oversubscription.
Frequently Asked Questions
Q: Can the M-49-V-V2 focus and zoom remotely?
A: Yes. The motorized lens adjusts both focal length (2.8–12mm) and focus point via ONVIF commands or native protocol. Once installed, you control zoom and focus from the VMS without a site visit.
Q: What's the actual 24/7 bandwidth reduction using H.265 instead of H.264?
A: H.265 typically cuts bitrate 40–60% compared to H.264 at the same resolution and frame rate, depending on scene complexity. On a 30-day retention policy with 24/7 recording, this translates to measurable storage savings per camera.
Q: Is the 40m IR range sufficient for typical outdoor parking lots?
A: At 40m (131 ft), the IR covers most standard parking lots and building perimeters. For larger open lots exceeding 150 feet, consider supplemental external IR or a higher-megapixel variant with extended range—consult your integrator for site-specific assessment.
Q: Does the M-49-V-V2 require external IR illuminators?
A: No. Built-in 850nm LEDs provide 40m range without external spotlights. External illumination is optional if you need extended range beyond 131 feet.
Q: Can I mask or define regions of interest to reduce false alarms?
A: Yes. On-board analytics support up to 8 ROI zones and 4 privacy-masking zones. Motion, intrusion, and tampering detection operate within defined regions, reducing alert fatigue from irrelevant motion (shadows, wind-blown debris).
Q: What VMS platforms support the motorized lens control?
A: Any ONVIF Profile S/T/G-compliant platform—Milestone XProtect, Genetec Security Center, Axis Camera Station, and most enterprise NVRs. Verify your VMS documentation for ONVIF motorized lens (PTZ) support before deployment.
When to Choose a Different Model
The M-49-V-V2 is optimized for outdoor deployments where motorized zoom and remote focus justify the cost. If your site requires fixed wide-angle coverage with no zoom flexibility, a fixed-lens 4MP variant will reduce cost and power consumption. If you need higher resolution (8MP or greater) for long-distance facial or plate identification, consider higher-megapixel options in the i-PRO catalog. For indoor-only deployments, an indoor varifocal model eliminates the IP67 enclosure overhead. For thermal imaging or dual-spectrum surveillance, this unit is not suitable—specify a thermal or multi-sensor variant.
Marty AllisonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The M-49-V-V2 lands in a useful gap: motorized zoom on a standard bullet form factor, PoE-powered, 4MP, and shipped with real on-board analytics (ROI, intrusion, tampering). Don't underestimate the practical value of remote focus. Most field technicians—and most system integrators—will tell you that getting lens selection exactly right at install time is rare. The motorized adjustment lets you dial in framing weeks or months after deployment, when the site's actual traffic patterns and lighting are visible.
Technical Highlights:
- 120dB WDR with 0.003 lux color sensitivity: This is the real standout. Parking garage entries, loading docks, and building lobbies with mixed sunlight and artificial lighting will not produce muddy shadows or blown highlights. You'll have usable detail in both the dark and bright regions of the same frame.
- H.265 at 2688×1520 @ 30 fps: H.265 is not just a compression gimmick here—it cuts bitrate 40–60%, which compounds across a fleet of cameras. On 24/7 recording, that's 15–30 TB annual storage savings per camera (depending on motion density). Real money.
- 9.6W PoE draw: Under 10 watts means you won't inadvertently overload an 802.3af switch. You can safely deploy 8–10 of these units on a single 60W budget switch without stress. No separate power supplies, no electrical circuit wrangling.
Deployment Considerations:
- Motorized lens requires VMS support: ONVIF Profile S/T/G covers most enterprise platforms, but consumer-grade NVRs or older systems may not pass lens control commands. Verify your VMS documentation before ordering. This is not a limitation of the camera—it's a compatibility gate you must clear.
- 40m IR is adequate for standard lots but not open fields: If your site is a sprawling industrial yard or farm-sized perimeter, 40m falls short. Supplemental external IR or a jump to a higher-MP variant becomes necessary. For urban parking, building perimeters, and warehouse yards under 150 feet, IR coverage is solid.
Position the M-49-V-V2 in mixed-lighting outdoor environments (parking, building entries, loading docks, perimeter fencing) where WDR and motorized zoom justify the cost—especially when site conditions are uncertain at install time or when identification detail (faces, plates) must be captured at variable distances without a camera swap.
