HPE Proliant DL385 GEN11 9124 3.0GHZ 16C 1P 2X32GB-R 8SFF MR408I-O 2X480GB SSD 2 - P86277-005

HPE P86277-005 ProLiant DL385 Gen11 9124 3.0GHz 16-Core 2U Rack Server

Overview

The HPE ProLiant DL385 Gen11, ordered under part number P86277-005, is a 2U rack-mount server configured with an AMD EPYC 9124 processor running at 3.0GHz with 16 cores, 1 processor socket populated, 64GB of registered DDR5 memory (2×32GB DIMMs), an HPE MR408i-o storage controller, eight small-form-factor drive bays, and two 480GB SATA SSDs pre-installed. This configuration targets compute workloads that benefit from AMD's EPYC architecture — including network video recorder back-end processing, video analytics servers, and enterprise data-center deployments requiring a dense, single-socket 2U footprint.

Key Features

• AMD EPYC 9124 at 3.0GHz, 16 cores: A single-socket Genoa-generation EPYC delivers high per-core performance and broad PCIe 5.0 lane availability — relevant when attaching multiple GPU cards or high-throughput NIC adapters for IP camera analytics workloads.
• 2×32GB DDR5 Registered DIMMs (64GB installed): DDR5 base configuration with room to expand; the DL385 Gen11 platform supports high-capacity DIMM populations for memory-intensive VMS databases or AI inference tasks without a chassis swap.
• HPE MR408i-o Storage Controller: The MR408i-o is an OCP-form-factor RAID controller — it keeps the primary PCIe slots free for expansion cards such as additional HBAs, NICs, or GPU accelerators, which matters in dense surveillance back-end racks where slot real estate is limited.
• 8× Small Form Factor Drive Bays with 2×480GB SSD pre-installed: Six bays remain open for additional SSD or HDD population. For continuous-write surveillance storage, plan NVMe or SAS expansion into those open bays — the 480GB pair alone is insufficient for multi-camera long-retention recording and is better suited as the OS/boot volume.
• 2U Rack Form Factor: Two rack units in a standard 19-inch cabinet. Verify your rack's depth capacity before ordering — consult the HPE QuickSpecs document for confirmed chassis depth, as the dimensional data in the distribution feed appears to reflect a unit-conversion artifact and should not be used for rack planning.

Integration and Compatibility

The DL385 Gen11 platform is broadly compatible with HPE's iLO 6 management stack, VMware vSphere, Microsoft Windows Server, and major Linux distributions. For video surveillance infrastructure, it integrates with VMS platforms including Milestone XProtect, Genetec Security Center, and Axis Camera Station when sized appropriately for channel count and retention targets. Pair with a managed PoE switch on the camera network side and a dedicated storage expansion shelf if retention exceeds what the 8-bay chassis can provide. Review the HPE server and storage catalog for compatible drive and memory expansion options validated for this platform.

Frequently Asked Questions

Q: What processor does the P86277-005 include?

A: The P86277-005 is configured with a single AMD EPYC 9124 processor running at 3.0GHz with 16 cores.

Q: How much memory comes installed in the P86277-005?

A: It ships with 64GB of DDR5 registered memory across two 32GB DIMMs, with additional DIMM slots available for expansion.

Q: What storage is included and how many drive bays are available?

A: Two 480GB SSDs are pre-installed. The chassis has 8 small-form-factor drive bays total, leaving 6 open for additional drives.

Q: What RAID controller does the P86277-005 use?

A: The HPE MR408i-o OCP-form-factor controller is included. This frees primary PCIe slots for additional expansion cards.

Q: Is the P86277-005 suitable as a video surveillance server?

A: The DL385 Gen11 platform is compatible with major VMS platforms. For surveillance use, evaluate channel count, retention requirements, and storage expansion needs — the included 2×480GB SSDs are best used as OS/boot volumes, with additional drives needed for camera recording storage.

Karl Wilson

When I look at the P86277-005, the configuration that stands out immediately is the MR408i-o OCP controller paired with 8 SFF bays — HPE made a deliberate slot-preservation choice here that matters if you're planning to add a GPU or dual-port 25GbE NIC for a high-channel VMS deployment.

Technical Highlights:

• AMD EPYC 9124, 16 cores at 3.0GHz: Single-socket Genoa gives you strong per-core throughput for concurrent video decode and analytics without the licensing overhead of a dual-socket configuration.
• MR408i-o OCP Controller: OCP form factor keeps the standard PCIe slots open — relevant when you need to add a storage HBA for a JBOD expansion shelf alongside a dedicated network card.
• 2×480GB SSD Pre-installed: Right-sized for a clean OS and VMS application install; treat these as your boot/application tier and budget for separate recording storage in the open SFF bays or an attached storage shelf.

Deployment Considerations:

• The 64GB DDR5 base is sufficient for moderate-channel VMS, but memory-intensive analytics (deep learning inference at scale) will require DIMM expansion before go-live — plan this at time of order to avoid a maintenance window.
• Do not use the dimensional data from the distribution feed for rack planning — verify chassis depth against the HPE QuickSpecs document for this model before reserving rack units.

This configuration is a practical fit for a mid-size physical security operations center running a software-based VMS on dedicated hardware — enough compute headroom for analytics, clean slot availability for network expansion, and a straightforward path to adding recording storage in the remaining six drive bays.
