HPE Proliant Compute DL580 GEN12 4P 24EDSFF X4 Tri-mode FIO Cable KIT - P80411-B21

HPE P80411-B21 Cable Kit

Overview

The HPE P80411-B21 is a Tri-mode FIO Cable Kit designed to facilitate specific connectivity requirements within HPE ProLiant Compute DL580 GEN12 servers. This kit provides the necessary cabling for integrating Tri-mode storage controllers, enabling flexible deployment options for SAS, SATA, and NVMe drives in a dense 24 EDSFF (Enterprise and Data Center SSD Form Factor) configuration. It is critical for ensuring proper data and power delivery to storage devices in high-density server environments.

Compatibility

This cable kit is specifically designed for the HPE ProLiant Compute DL580 GEN12 server platform. It supports configurations utilizing 24 EDSFF drives and requires Tri-mode storage controllers. Compatibility is limited to this specific server model and storage controller type; verify your server's configuration before ordering.

Installation Notes

Installation requires opening the server chassis and connecting the provided cables from the Tri-mode controller to the EDSFF drive backplane. Ensure the server is powered down and properly grounded before beginning installation. Refer to the HPE ProLiant DL580 GEN12 server documentation for detailed installation procedures and pinout diagrams.

What's in the Box

• 1x HPE P80411-B21 Tri-mode FIO Cable KIT
