HPE EL 960GB NVME MU M.2 22110 PM9A3 SSD - P49021-B21

HPE P49021-B21 960GB NVMe Gen4 M.2 22110 Extended Temp SSD

Overview

The HPE P49021-B21 is a 960GB NVMe Gen4 SSD in M.2 22110 form factor, purpose-built for surveillance systems, edge computing appliances, and industrial deployments where extended temperature operation and mixed-use workload stability matter. This drive pairs mainstream performance mixed-use characteristics with extended temperature rating—a combination that keeps recording systems running reliably in server rooms, outdoor cabinet enclosures, and temperature-variable industrial environments where standard drives throttle or fail.

Key Features

• 960GB capacity with NVMe Gen4 interface: Delivers sequential throughput suitable for continuous multi-stream video recording and simultaneous playback without bottlenecking on the storage layer. Gen4 means you're not leaving bandwidth on the table if your surveillance appliance or NVR supports PCIe 4.0.
• M.2 22110 form factor: Fits directly into compatible HPE Edgeline systems, ProLiant servers used as NVR platforms, and industrial/embedded appliances with M.2 slots rated for the extended 22110 length. No adapter, no compatibility guesswork—mechanical fit is guaranteed across HPE product lines.
• Mainstream Performance Mixed Use (PM9A3): Balanced for read/write performance across typical surveillance and edge workloads—no overprovisioning for sequential-only or synthetic bench scoring. Real-world mixed-use means steady performance whether you're writing continuous video streams, running edge analytics, or reading back clips for investigation.
• Extended Temperature Rating: Operates reliably beyond standard 0–70°C range. Surveillance cabinets in unheated warehouses, outdoor network closets, or equipment rooms without climate control will see drive stability where consumer or standard commercial SSDs would thermal-throttle and fail. Eliminates one failure mode on edge deployments.
• HPE sourced and tested: Direct manufacturer sourcing means no grey-market, no parallel imports, no firmware variants. Fits HPE support workflows and warranty terms without carrier surprises.
• Suitable for 24/7 surveillance recording: Mixed-use tuning handles constant write load (video ingest) plus random reads (clip retrieval, playback, forensics) without wearing out prematurely or starving other system tasks on CPU or memory.

Integration and Compatibility

The P49021-B21 integrates with HPE Edgeline EL series systems (EL300, EL1000, EL8000 appliances for industrial IoT, surveillance, and edge analytics). It also fits HPE ProLiant servers configured as NVR platforms when those servers have available M.2 Gen4 slots. Confirm your target appliance or server datasheet for M.2 slot availability, PCIe generation, and thermal envelope—extended temperature rating handles the ambient, but the host system must expose the M.2 connector. Not suitable for external USB enclosures or SATA-only environments.

Storage and Performance Specifications

Capacity of 960GB provides 7–10 days of typical 24/7 HD multi-camera recording (assuming 4–6 Mbps per stream, H.265 encoding). Gen4 NVMe throughput (up to 7,400 MB/s typical, depending on revision) keeps ingest latency under 1ms, critical for real-time event logging and synchronized multi-camera frames. Extended temperature operation extends drive life in thermally challenging cabinet and outdoor installations where standard SSDs would see accelerated degradation above 55°C ambient.

What's in the Box

The P49021-B21 ships as a bare drive. No mounting bracket, no cables, no thermal pads included—M.2 installation assumes the host system provides the socket, heatspreader (if required), and any thermal management. Confirm your target HPE appliance documentation for any additional thermal interface materials or mounting rails needed.

Frequently Asked Questions

Q: Will the P49021-B21 work in my HPE Edgeline EL300 surveillance appliance?

A: Yes, if the EL300 has an available M.2 22110 slot. Confirm your specific EL300 configuration datasheet for M.2 support and PCIe generation. Direct HPE sourcing means no compatibility surprises.

Q: Does the extended temperature rating mean I can skip cooling in my outdoor cabinet?

A: Extended temperature rating means the drive tolerates higher ambient without throttling or failure—but your host appliance (NVR, appliance CPU, power supply) still needs thermal management. The drive is one component; the system thermal design must still dissipate total heat load.

Q: How long will 960GB last for continuous video recording?

A: Retention depends on bitrate and encoding. At 5 Mbps per camera (H.265, typical HD): one 960GB drive holds roughly 7–10 days of 24/7 footage from a single camera, or 1–2 days from a 4–6 camera system. Adjust for your actual scene complexity and codec selection.

Q: Can I use the P49021-B21 as a boot drive for an NVR or appliance?

A: Yes—NVMe boot is standard on modern HPE systems. Confirm your platform supports M.2 booting in BIOS. Once installed, the drive can serve as both OS and recording storage, though dedicated recording storage is preferred to avoid OS/video I/O contention.

Q: What warranty does the P49021-B21 carry?

A: HPE provides manufacturer warranty; confirm the specific duration with your reseller or HPE. Extended temperature and industrial-grade sourcing may include longer terms than consumer SSDs.

Q: Is there a DBAN or secure erase option if I need to decommission the drive?

A: Standard NVME secure erase is supported via UEFI or Linux tools. Confirm your HPE appliance or server platform documentation for approved sanitization procedures before repurposing or recycling.

Karl Wilson

The P49021-B21 hits a real deployment sweet spot for surveillance platforms running in thermally marginal spaces—unheated loading docks, rooftop cabinets, outdoor network closets. Extended temperature operation means the drive won't throttle at 50–55°C ambient like a standard commercial SSD would. I've seen too many surveillance systems degrade or fail mid-summer because storage couldn't handle the cabinet heat; the extended rating on the P49021-B21 eliminates that failure mode entirely.

Technical Highlights:

• NVMe Gen4 interface: Sequential throughput of 7,400 MB/s nominal keeps ingest latency near zero—critical when synchronizing multiple HD streams or running edge analytics alongside recording on the same appliance. Gen4 futureproofs against bandwidth starvation as camera resolution climbs.
• 960GB capacity: Holds 7–10 days of 24/7 single-camera footage at typical HD bitrate (5 Mbps H.265). On a 4-camera system, expect 2–3 days retention, which is realistic for most surveillance rollback windows without requiring a separate SSD array.
• Extended temperature rating: Operates reliably to 60°C+ ambient where standard drives would thermal-throttle or enter power-saving modes. Real benefit: no surprise performance cliffs or premature SSD wear-out in summer heat or poorly cooled enclosures.

Deployment Considerations:

• Confirm your target HPE appliance or ProLiant NVR platform has an M.2 22110 slot available—not all configurations include NVMe support. Edgeline EL1000 and newer typically support it; verify older models against the datasheet.
• Extended temperature handles ambient; it doesn't eliminate the need for appliance-level thermal design. Your NVR or surveillance appliance CPU, PSU, and overall cabinet airflow still must be sized for the total heat load. This drive is one part of the solution.

Deploy the P49021-B21 in outdoor or unheated-building surveillance platforms where you're already using HPE Edgeline or ProLiant hardware. It's the right SSD when thermal headroom is tight and you need 7–10 days of retention without overprovisioning capacity.
