HPE DL3XX GEN12 1U 2SFF X4 TM BP KIT - P75086-B21

HPE P75086-B21 1U 2SFF X4 TM BP KIT

Overview

The HPE P75086-B21 is a 1U 2SFF X4 Through-Module Backplane Kit. This component is designed to integrate specific storage configurations within compatible HPE ProLiant server chassis, enabling the connection of 2.5-inch Small Form Factor (SFF) drives to the server's motherboard or RAID controller via a x4 interface. It is critical for building out storage capacity in environments requiring dense, high-performance drive arrays within a 1U rack footprint.

Compatibility

This kit is engineered for specific HPE ProLiant DL3XX Gen12 server models. It is essential to verify compatibility with your exact server configuration, as it is designed for a particular chassis and backplane architecture. Refer to HPE's official documentation for the DL3XX Gen12 series to confirm if the P75086-B21 is listed as a supported option for your server model and desired drive configuration.

Installation Notes

Installation requires opening the server chassis and connecting the backplane kit to the designated motherboard or RAID controller ports. Ensure proper seating of all connectors and secure mounting of the backplane. Torque specifications for any associated screws should be followed as per HPE's service manual. Proper cable management is advised to maintain airflow within the 1U chassis.

What's in the Box

• 1x HPE P75086-B21 1U 2SFF X4 TM BP Kit
