HPE DL3XX G12 Sff/edsff Dp/usb/odd KIT - P72227-B21

HPE P72227-B21 Concise Descriptor

Overview

The HPE P72227-B21 is a specific kit designed to expand the connectivity and storage options for HPE ProLiant DL3XX Gen12 servers. This accessory enables the integration of Small Form Factor (SFF) and Enterprise-Specific Form Factor (EDSFF) drives, along with DisplayPort (DP), USB, and an Optical Disk Drive (ODD) bay. It addresses scenarios where a server needs enhanced local storage density or expanded peripheral support beyond its base configuration, often required for complex data logging, local caching, or specialized boot media needs in enterprise environments.

Compatibility

This kit is engineered for HPE ProLiant DL3XX Gen12 server platforms. Specifically, it is designed to fit within the chassis of the DL360 Gen12 and DL380 Gen12 models, providing the necessary physical and electrical interfaces to support the specified drive types and ports. Ensure your server model is within the Gen12 generation and supports the required drive bay configurations for this kit.

Installation Notes

Installation requires opening the server chassis and physically mounting the kit components into designated bays. Proper seating of all connectors, including drive backplanes and internal cabling for DP and USB, is critical for functionality. Refer to the HPE ProLiant DL3XX Gen12 server documentation for detailed installation procedures, including any specific torque requirements for mounting screws and connector seating guidelines. A Phillips head screwdriver is typically required.

What's in the Box

• 1x HPE DL3XX G12 SFF/EDSFF DP/USB/ODD KIT
