HPE DL380A GEN11 8SFF X4 U.3 NVME BC KIT - P54302-B21

HPE P54302-B21 8SFF U.3 NVMe BC Kit

Overview

The HPE P54302-B21 is a backplane cable kit designed to enable U.3 NVMe drive connectivity in specific HPE ProLiant server configurations. This kit ensures that the necessary cabling and connectors are present for integrating high-speed NVMe storage, crucial for demanding workloads like video analytics platforms or large database operations where I/O performance is paramount. It addresses the need for robust, direct-attached storage solutions within the server chassis.

Compatibility

This kit is specifically designed for HPE ProLiant DL380 Gen11 servers configured with an 8SFF (Small Form Factor) drive bay. It is intended for use with U.3 NVMe drives, providing the correct interface and power delivery for these high-performance storage devices. Verify your server's chassis and drive bay configuration against the HPE QuickSpecs for the DL380 Gen11 to confirm compatibility before purchase.

Installation Notes

Installation requires opening the server chassis and connecting the provided cables to the motherboard and the drive backplane. Ensure the server is powered off and properly grounded before beginning installation. Specific torque values for any mounting screws are not provided but standard practice for server hardware should be followed. This kit facilitates the physical connection of U.3 NVMe drives to the server's storage controller or backplane.

What's in the Box

• 1x HPE P54302-B21 Backplane Cable Kit
