HPE DL36X GEN10+ LP Riser KIT - P26471-B21

HPE P26471-B21 Low-Profile Riser Kit for ProLiant DL36X Gen10+

Overview

The P26471-B21 is a low-profile riser kit designed to expand PCIe slot availability in HPE ProLiant DL36X Gen10+ servers. If you're configuring a DL36X Gen10+ for a workload that requires additional low-profile expansion cards — network adapters, HBAs, or capture cards — this riser kit provides the physical mounting and electrical interface to make that possible without modifying the base chassis. At 8.74" x 9.92" x 2.56" and 0.53 lb, it fits within the chassis envelope of supported 1U/2U DL36X Gen10+ platforms without displacing other internal components.

Compatibility

This kit is designed specifically for HPE ProLiant DL36X Gen10+ platforms. The "LP" designation confirms it is built for low-profile (half-height) add-in cards only — standard full-height cards will not seat correctly. Verify your specific DL360 Gen10+ or DL365 Gen10+ configuration guide to confirm riser slot assignment before ordering, as HPE Gen10+ platforms support multiple riser positions and not all positions accept every riser SKU interchangeably. If your system already ships with a riser populated, check whether P26471-B21 is an upgrade, replacement, or secondary-slot addition per the server components bill of materials for your chassis.

Installation Notes

Installation follows HPE's standard tool-assisted riser procedure: power down, remove the access panel, seat the riser into the designated motherboard connector, and secure with the captive screw. No special torque spec is published for this SKU — use standard HPE chassis screw torque practices. Low-profile cards installed into this riser must not exceed the chassis height clearance for the DL36X Gen10+ 1U envelope. Confirm card bracket type (LP) before procurement to avoid a second return cycle.
