HPE DL360 GEN12 4EDSFF X4 P1 B5 CBL KIT - P76505-B21

HPE P76505-B21 Concise Descriptor

Overview

The HPE P76505-B21 is a cable kit designed for specific HPE ProLiant DL360 Gen12 server configurations, particularly those utilizing 4 EDSFF (Enterprise & Data Center SSD Form Factor) drives and the P1 B5 backplane. This kit provides the necessary cabling to connect these drives to the server's motherboard or RAID controller, ensuring proper data and power delivery in a dense server environment. It is essential for maintaining system integrity and performance when expanding or rebuilding storage within compatible HPE servers.

Compatibility

This cable kit is specifically designed for the HPE ProLiant DL360 Gen12 server. It is intended for configurations that feature the 4 EDSFF drive bays and the P1 B5 backplane. Verification against your server's exact configuration and backplane model is recommended before purchase to ensure proper fit and function.

Installation Notes

The HPE P76505-B21 cable kit requires careful installation within the server chassis. Ensure the server is powered down and all components are discharged before handling internal cables. Connectors should be seated firmly to prevent intermittent connectivity. Refer to the HPE ProLiant DL360 Gen12 service manual for detailed installation procedures and pinout diagrams specific to the P1 B5 backplane and EDSFF drive configurations.

What's in the Box

• 1x HPE P76505-B21 Cable Kit
