HPE DL320 GEN12 8SFF X1 U.3 PCIE CBL KIT - P75088-B21

HPE P75088-B21 Concise Descriptor

Overview

The HPE P75088-B21 is a PCIe cable kit designed to facilitate the installation of PCIe devices within HPE ProLiant DL320 Gen12 8SFF server configurations. This kit specifically addresses the need for proper connectivity when adding U.3 storage controllers or other PCIe expansion cards, ensuring a stable and efficient data path. It is engineered for environments requiring direct hardware integration for enhanced storage performance or specialized I/O expansion.

Compatibility

This cable kit is confirmed for use with the HPE ProLiant DL320 Gen12 server, specifically models configured with 8 Small Form Factor (8SFF) drive bays. It is intended for use with U.3 PCIe backplanes and controllers that require this specific cabling solution for proper signal integrity and power delivery.

Installation Notes

The kit includes PCIe cabling components. Installation requires opening the server chassis and connecting the cables between the motherboard's PCIe slots and the U.3 backplane or controller. Ensure the server is powered down and properly grounded before proceeding. Refer to the HPE ProLiant DL320 Gen12 server documentation for detailed installation procedures and component placement.

What's in the Box

• 1x HPE P75088-B21 PCIe Cable Kit
