StarTech HSB100SATBK 3.5-Inch SATA Hot-Swap Drive Bay Adapter

Overview

The StarTech HSB100SATBK converts a standard 5.25-inch internal bay into a tool-free, hot-swappable home for any 3.5-inch SATA hard drive. If you're running a surveillance NVR, a recording workstation, or any machine that needs periodic drive swaps without powering down, this is the hardware layer that makes it practical. At 6 Gbps SATA throughput and a 50,000-cycle insertion rating, this is a purpose-built mechanism — not a repurposed consumer tray. The black aluminum-and-plastic construction fits cleanly into tower workstations and rackmount chassis with an available 5.25-inch bay, and the single power/activity LED gives you an immediate visual on drive status.

For network video recorders and on-site recording servers where swap time means lost footage windows, the HSB100SATBK eliminates the need to shut the system down to rotate a drive. That matters in 24/7 surveillance environments more than almost anywhere else.

Key Features

• 6 Gbps SATA Data Transfer Rate: Saturates even high-RPM 3.5-inch surveillance drives — you won't hit a bandwidth ceiling writing multi-camera streams to a hot-swapped disk. The 7-pin SATA data connector and 15-pin SATA power connector on both host and drive sides are standard, so no adapters are needed between the bay and your motherboard or backplane.
• 50,000+ Cycle Insertion Rating: That's roughly 137 swaps per day for a year before you've used 5% of the rated life. In practice, for surveillance sites rotating drives weekly or monthly, this mechanism will outlast the drives themselves. Engineering that cycle rating into an aluminum-and-plastic housing is the detail that separates a production-grade bay from a budget tray.
• Tool-Free Hot-Swap Operation: Drives slide in and out without screws, brackets, or powering down the host system. On a surveillance recorder that can't afford downtime, that means rotating archival drives mid-shift without interrupting recording on other channels.
• Single Drive Power/Activity LED: The LED indicator confirms the drive is powered and active at a glance — useful in rack environments or tower NVRs where you can't easily see the drive itself. No ambiguity about whether the swap completed successfully.
• Aluminum and Plastic Construction, 261g: At 9.2 oz, the bay adds negligible weight to the chassis, and the aluminum component contributes to heat dissipation — relevant when the drive inside is running continuous write cycles under surveillance workloads.
• 0°C to 50°C Operating Range: Covers standard data center and office equipment room environments. Pair this with a properly ventilated chassis and you won't hit thermal limits under normal surveillance recording duty cycles.
• 5~85% RH Non-Condensing Operating Humidity: Handles typical indoor environments without issue. The non-condensing specification matters in climate-controlled server rooms where temperature swings could otherwise cause moisture problems.
• Compact Form Factor — 7.2 x 5.9 x 1.7 Inches: Designed to occupy exactly one 5.25-inch drive bay. No modification to the chassis required beyond removing the existing bay cover.

Integration and Compatibility

The HSB100SATBK works with any 3.5-inch SATA hard drive — including high-capacity surveillance-rated drives commonly used in IP camera storage and on-site recording systems. The host side uses standard SATA data (7-pin) and SATA power (15-pin) connections, which means it connects directly to a motherboard SATA port and a standard power supply Molex-to-SATA or SATA power cable. No proprietary connectors, no driver installation required.

This bay fits any desktop tower or rackmount enclosure with an open 5.25-inch drive bay. It's particularly practical alongside surveillance-optimized hard drives that are designed for continuous-write workloads — rotating those drives for offsite archival or capacity expansion becomes a one-minute operation rather than a maintenance event. For guidance on matching storage capacity to camera count and retention requirements, the storage and retention planning guide is a useful reference before selecting drive capacity.

The HSB100SATBK ships with a 2-year manufacturer warranty, which is the relevant coverage period for a mechanical interface component of this type.

Frequently Asked Questions

Q: Can the HSB100SATBK hot-swap drives while the computer is running?

A: Yes — the HSB100SATBK is designed specifically for hot-swap operation, allowing you to remove and insert 3.5-inch SATA drives without powering down the host system. Your operating system and SATA controller must also support hot-swap for this to function correctly.

Q: What drive types are compatible with the HSB100SATBK?

A: The HSB100SATBK is compatible with 3.5-inch SATA hard drives. It uses standard 7-pin SATA data and 15-pin SATA power connectors on both the host and drive sides.

Q: What is the data transfer rate of the HSB100SATBK?

A: The HSB100SATBK supports up to 6 Gbps SATA data transfer, which is the current SATA III standard and sufficient for all current 3.5-inch SATA hard drives.

Q: How many insertion cycles is the HSB100SATBK rated for?

A: The HSB100SATBK carries a 50,000+ cycle insertion rating, meaning the drive connector and tray mechanism are engineered to withstand at least 50,000 drive insertions before wear becomes a concern.

Q: What chassis bay does the HSB100SATBK require?

A: The HSB100SATBK installs into a standard 5.25-inch internal drive bay. It measures 7.2 x 5.9 x 1.7 inches and requires no chassis modification beyond removing the existing 5.25-inch bay cover.

Q: What is the warranty on the HSB100SATBK?

A: The HSB100SATBK includes a 2-year manufacturer warranty.

Ted Perry

The spec I keep coming back to on the HSB100SATBK is that 50,000-cycle insertion rating. Most integrators evaluate hot-swap bays on throughput alone — 6 Gbps SATA III is table stakes at this point — but the mechanical longevity of the connector interface is what determines whether this bay is still functional in year four of a surveillance deployment. At a drive rotation frequency of once per week, you'd reach 50,000 cycles in nearly 1,000 years of operation. Even at daily swaps, you're looking at decades of rated life.

Technical Highlights:

• 6 Gbps SATA III Throughput: Matches the interface speed of all current 3.5-inch SATA surveillance drives — no bottleneck between the drive and the recording system's storage controller.
• 50,000+ Cycle Insertion Rating: Engineered for repeated swap operations over the product's full service life — the mechanical connector is the failure point in most cheaper bays, and this spec directly addresses that.
• 0°C to 50°C Operating Range: Aligns with standard equipment room and server closet environments; won't require special thermal management in a typical NVR or recording workstation enclosure.

Deployment Considerations:

• Hot-swap functionality depends on both the bay and the host system — confirm your motherboard SATA controller and operating system support SATA hot-plug before relying on live drive swaps in a production recording environment.
• The operating temperature ceiling of 50°C means you should not install this in poorly ventilated chassis running high-wattage drives in warm ambient conditions — verify chassis airflow before committing to a 24/7 write workload.

The HSB100SATBK is the right fit for surveillance recording workstations and tower NVRs where an operator needs to rotate archival drives on a defined schedule — weekly evidence pulls, offsite backup rotations, or capacity tier management — without scheduling a maintenance window to shut down the recorder.
