Middle Atlantic Horiz Rack 2U+2U 36D - VWM-2-2-36K-PW

Middle Atlantic VWM-2-2-36K-PW Horizontal Wall Mount Rack, 2U+2U, 36-Inch Height

Overview

The Middle Atlantic VWM-2-2-36K-PW is a 4U (2U+2U configuration) steel wall mount rack designed for integrators who need rack-density in locations where a floor-standing enclosure isn't practical — think security head-end closets, above-ceiling equipment spaces, or utility rooms with limited floor clearance. At 36 inches tall with a 25-inch width and a genuine usable depth of 27.8 inches, it accommodates real-world equipment without the compromise of a shallow-depth wall box. Built in the USA and TAA compliant, it fits government and enterprise procurement requirements straight off the shelf.

The VWM-2-2-36K-PW (often searched as VWM 2 2 36K PW) ships in a putty wrinkle powder-coat finish — the same tone common in commercial AV and security infrastructure, so it blends into finished mechanical and electrical spaces without looking out of place.

Key Features

• 150 lb UL-Rated Load Capacity: UL listing on the 150 lb (68 kg) load rating means the number is verified, not a marketing claim. You can fill this rack with a pair of NVRs, a managed PoE switch, and a UPS battery module without worrying about the wall anchor math being the weak link — the rack itself is rated for the weight.
• 27.8-Inch Usable Depth: The 12-inch overall cabinet depth masks a 27.8-inch (70.6 cm) usable equipment depth. That's enough clearance for 1U rack-mount NVRs, enterprise switches with rear cable management, and most 1U UPS units. Shallow-depth wall racks that force you to leave the door off or hang equipment at an angle are a different product class entirely.
• 4U Rack Space (2U+2U Split): The dual-zone layout — two independent 2U sections — gives you physical separation between equipment types. Common deployment: top zone for active network gear (PoE switch, router), bottom zone for recording or power equipment. Keeps cable runs logical and simplifies future servicing.
• 10-32 and Cage Nut Rail System: Both standard rail formats are supported. 10-32 tapped rails handle most security and AV rack-mount gear natively; cage nut compatibility means server-class equipment with square-hole requirements mounts without adapters. You're not locked into one equipment ecosystem.
• Full Solid Door with 25mm x 150mm Swing Handle: The full solid door keeps dust off equipment and provides a physical tamper barrier in semi-public locations. The 25mm x 150mm swing handle is sized for gloved hand operation — relevant during installation or in mechanical rooms where you're not working in shirt sleeves.
• Steel Construction, Putty Wrinkle Powder Coat Finish: Welded steel at 70.4 lbs (31.9 kg) net weight means this cabinet is rigid — panels don't flex when you're torquing down rack screws or routing stiff conduit. The wrinkle powder coat hides minor contact marks better than smooth paint, which matters in working equipment spaces.
• TAA Compliant, Made in USA: Federal and state government procurement, DoD projects, and GSA schedule work all require TAA compliance. This unit qualifies. Country of origin is documented as USA for Federal Ops purposes — not a vague assembly claim.
• GREENGUARD Certified (CSA Listed): GREENGUARD certification confirms low chemical emissions. Relevant for installations in occupied spaces — classrooms, courtrooms, healthcare — where air quality standards apply to installed equipment.
• Forward Compatible Design: Middle Atlantic's forward compatibility designation means this enclosure is engineered to accept future accessories and upgrade panels within the VWM product family. If your client's head-end grows, you're not scrapping the cabinet.

Integration & Compatibility

The VWM-2-2-36K-PW integrates into standard rack infrastructure via 10-32 and cage nut rails, covering virtually the entire range of network video recorders, managed PoE switches, patch panels, and 1U UPS units used in commercial security installations. The 27.8-inch usable depth accommodates deep 1U/2U equipment that shorter wall enclosures cannot fit. For projects specifying Middle Atlantic rack systems, this cabinet accepts Middle Atlantic's accessory ecosystem including blanks, fan trays, and horizontal cable managers that fit the standard EIA rail spacing.

TAA compliance and US origin make the VWM-2-2-36K-PW a direct fit for government facility projects, DOD integrations, and any bid requiring Buy American or TAA provision adherence. Pair it with a quality PoE switch and a rack-mount UPS for a complete head-end package in constrained wall-mount environments. Integrators specifying wall mount enclosures for school, courthouse, or municipal security deployments will find the GREENGUARD certification removes a common procurement objection in those verticals.

Frequently Asked Questions

Q: Is the VWM-2-2-36K-PW TAA compliant?

A: Yes. The VWM-2-2-36K-PW is TAA compliant and manufactured in the USA, with Federal Ops Country of Origin documented as USA. It qualifies for government and GSA schedule procurement requiring TAA compliance.

Q: What is the usable equipment depth inside the VWM-2-2-36K-PW?

A: Usable depth is 27.8 inches (70.6 cm). The overall cabinet depth is 12 inches, but the internal equipment clearance extends to 27.8 inches — sufficient for standard 1U rack-mount NVRs, managed switches, and most 1U UPS units.

Q: What is the maximum weight this rack can hold?

A: The VWM-2-2-36K-PW carries a UL-rated load capacity of 150 lbs (68 kg). This is a verified UL listing, not a manufacturer self-certification.

Q: What rail type does the VWM-2-2-36K-PW use?

A: It supports both 10-32 tapped rails and cage nut rails, covering standard security/AV rack-mount equipment as well as server-class gear requiring square-hole cage nut mounting.

Q: Is the VWM-2-2-36K-PW GREENGUARD certified?

A: Yes, it carries CSA GREENGUARD certification for low chemical emissions. This is relevant for installations in occupied spaces such as schools, healthcare facilities, and courtrooms where indoor air quality standards apply.

Q: How much does the VWM-2-2-36K-PW weigh, and what does it ship at?

A: Product weight is 70.4 lbs (31.9 kg). Shipping weight is 80 lbs (36.3 kg). Plan wall anchor and installation accordingly — this is a two-person lift for most wall installations.

Marty Allison

The spec I keep coming back to on the VWM-2-2-36K-PW is the 27.8-inch usable depth. Most wall enclosures in this height class top out at 18 to 22 inches of real clearance, which forces you to either hang equipment loose on the rails with the door removed or spec a floor-standing cabinet you don't have room for. Middle Atlantic solved that with this unit — you're getting genuine data-closet depth in a wall-mount form factor, and the 150 lb UL load rating means you can actually fill those 4U of rail space without second-guessing the anchor job.

Technical Highlights:

• 27.8 in Usable Depth: Accommodates full-depth 1U NVRs, managed PoE switches, and rack-mount UPS units that typical shallow wall enclosures physically cannot close around — eliminates the door-removal workaround on crowded head-ends.
• 150 lb UL-Rated Capacity: The UL listing makes this verifiable for project submittals — not a self-rated figure. Load four fully populated 1U units and you're still well under the ceiling.
• TAA / Made in USA: Country of origin is USA per Federal Ops documentation. No additional certification chase for government or educational facility bids — it satisfies TAA provisions as-specified.

Deployment Considerations:

• At 70.4 lbs net (80 lbs shipping), this is a serious two-person installation. Wall blocking or a rated strut-channel backing plate behind the drywall is non-negotiable — don't attempt anchor-only into 16-inch stud centers with a fully loaded cabinet.
• The 2U+2U split configuration is fixed — you're not getting 4U of continuous open rail. Verify your equipment's RU footprint against the zone layout before ordering, particularly if you're mounting a 2U+ device that spans the divider.

The VWM-2-2-36K-PW is the right call for school security head-ends, municipal facility IDF closets, and healthcare corridor equipment rooms where floor space is constrained, GREENGUARD certification is a procurement requirement, and TAA compliance is non-negotiable. It is not the choice for a heavy compute or storage buildout that will exceed 4U — go floor-standing for that.
