Honeywell CCB22-100BT-03N-N Xenon XP 1952g Charge Base
The CCB22-100BT-03N-N is a dedicated charge and communication base station engineered specifically for the Honeywell Xenon XP 1952g area imager barcode scanner. Unlike generic multi-device charging cradles, this purpose-built dock integrates optimized power delivery, wireless synchronization, and industrial durability into a single platform. Deploy it across warehouse, manufacturing, and distribution environments where multi-shift scanner rotations demand predictable uptime and straightforward lifecycle management.
Key Features
- PoE Class 2 (802.3af) Power Support: The base draws under 13W via standard PoE infrastructure, meaning you can distribute charging stations across your facility without dedicated 24VDC power supplies at each location. Simplifies power planning significantly if your network already runs PoE backbone infrastructure.
- Bluetooth 4.2 Wireless Connectivity: Cable-free operation reduces deployment friction and scanner tether points. Wireless synchronization pairs naturally with warehouse management systems (WMS) supporting scanner fleets. No tethered power or data lines means faster asset handoffs between workers on different shifts.
- USB Wired Connectivity Option: Complements Bluetooth for scenarios requiring guaranteed synchronization—critical in secure facilities or high-noise RF environments where wireless reliability is uncertain. Dual-mode flexibility without added cost.
- IP65 Environmental Rating: Dust and water ingress resistance keeps the base station operational in dock areas, loading bays, and manufacturing floors where washdown and particulate contamination are routine. The base meets the same durability standard as the scanner it charges, so environmental conditions won't degrade the docking platform.
- 2.0 m (6.5 ft) Drop Certification: Purpose-built for industrial handling. Drop resilience on the dock or workstation floor means fewer replacement cycles and lower total cost of ownership over a multi-year deployment. This spec alone justifies the premium over generic universal cradles.
- 1D/2D Area Imager Optimization: Seamless integration with Xenon XP 1952g hardware ensures charging contacts, data protocol, and firmware updates are fully aligned. No adapter quirks or compatibility guesswork—Honeywell's base station and scanner work as a tested pair.
Deployment Reality
Organizations standardizing on area imager barcode scanners across multiple distribution centers should plan charge base capacity around shift-change windows. A common mistake: underestimating the number of bases needed. If scanner rotation happens in 15–20 minute handoff intervals but charging takes 60–90 minutes, you'll need roughly 3–4 bases per active scanner to maintain throughput without idle waiting. The CCB22-100BT-03N-N's PoE support allows you to consolidate power delivery to a central uninterruptible PSU rather than deploying multiple power adapters—a meaningful simplification if your facility already runs PoE.
For facilities managing regulatory compliance (healthcare asset tracking, pharmaceutical lot traceability), the dedicated Honeywell base station maintains a verified charge/sync audit trail compared to aftermarket universal charging cradles. Bluetooth 4.2 pairs well with WMS platforms that already support wireless scanner fleets, eliminating the need for redundant integration work.
When to Consider Alternatives
If your deployment requires indoor-only charging in a climate-controlled office or data center environment, a simpler non-IP-rated base may reduce cost. If you're mixing multiple scanner models across your facility, a universal multi-device cradle might consolidate SKU count—but you'll trade away the optimized charging profile and contact reliability that a dedicated base provides. The CCB22-100BT-03N-N is the right choice when scanner standardization, shift-based charging rotation, and harsh-environment durability justify the premium.
Frequently Asked Questions
Q: Does the CCB22-100BT-03N-N work with other Honeywell scanner models?
A: No. This base station is engineered specifically for the Xenon XP 1952g area imager. Using it with other scanner models risks charging contact misalignment and synchronization failures. Honeywell publishes a compatibility matrix in the datasheet—verify model compatibility before deploying across mixed fleets.
Q: What is the charge time from empty to full on the CCB22-100BT-03N-N?
A: The base specification does not publish a discrete charge duration. Charge time depends on the Xenon XP 1952g's battery capacity and the base's power delivery rate. Consult the Xenon XP 1952g datasheet for battery specs and typical charge profiles.
Q: Can I daisy-chain multiple CCB22-100BT-03N-N bases on a single PoE switch port?
A: No. Each base requires its own PoE power source. Daisy-chaining is not supported and would risk power budget overload on a single port. Plan one PoE-capable switch port per base station.
Q: Is the CCB22-100BT-03N-N rated for outdoor use?
A: IP65 protects against dust and water ingress, so brief outdoor exposure (dock overhangs, loading bay transitions) is acceptable. However, sustained outdoor deployment in direct sunlight or extended rain is not recommended. For permanent outdoor installation, consult Honeywell on environmental enclosure options.
Q: What happens if the base is dropped from above 2.0 m?
A: Damage is likely. The 2.0 m (6.5 ft) drop certification is the tested threshold. Drops beyond this height may crack internal circuitry or degrade charging contacts. Plan workstation placement to minimize drop risk, and budget replacement units accordingly.
Q: Does the CCB22-100BT-03N-N require firmware updates?
A: Yes. Honeywell periodically releases firmware updates for charge bases and paired scanners to maintain compatibility and patch security vulnerabilities. Plan for periodic USB-wired synchronization with a management workstation to deploy updates across your base station fleet.
The CCB22-100BT-03N-N solves a real pain point in high-volume scanning environments: coordinating multiple shift rotations without idle scanner downtime. The PoE Class 2 power model is the key differentiator here—it lets you deploy charging stations wherever your network backbone already runs, without forcing separate 24VDC daisy-chains across the dock. For a facility managing 20+ active scanners, that's a significant infrastructure simplification.
Technical Highlights:
- PoE Class 2 (802.3af) Draw: Sub-13W consumption means this base won't strain a standard switch port. You can deploy multiple bases on a single 60W PoE+ switch without breaching power budget, compared to alternative bases requiring discrete power adapters at each charging station.
- Bluetooth 4.2 + USB Dual Mode: Wireless operation simplifies day-to-day scanning workflows, but USB fallback is essential for firmware updates and compliance audits requiring guaranteed wired synchronization. The flexibility matters more than it sounds in highly regulated environments.
- IP65 + 2.0 m Drop Combination: This pairing is uncommon in third-party charging solutions. Dock environments aren't gentle—pallet jack impacts, spilled liquids, and accidental floor drops are routine. The certification proves Honeywell engineered this base for warehouse reality, not office conditions.
Deployment Considerations:
- The CCB22-100BT-03N-N is Xenon XP 1952g exclusive. Cross-model incompatibility is absolute. If your facility mixes scanner families, you'll need separate base stations for each model—a hidden cost often overlooked in multi-scanner deployments.
- Charge capacity planning is critical: a single base cannot sustain continuous 24/7 scanning across one active unit if charge time exceeds 90 minutes. Model the math around your shift structure—a facility with three 8-hour shifts needs roughly three bases per scanner to avoid idle time.
- Bluetooth 4.2 range is approximately 50–100 meters in open air, but RF obstacles (metal racks, dense cardboard stacking, electrical noise) reduce effective range significantly. Test wireless synchronization in your actual dock environment before rolling out across multiple bases.
The CCB22-100BT-03N-N is the right choice for standardized Xenon XP 1952g fleets in dock and manufacturing environments where IP65 durability, PoE power consolidation, and verified charging reliability justify the cost premium over universal cradles. Skip it if you're mixing scanner models or deploying to climate-controlled office environments where cheaper alternatives suffice.
