Honeywell 1962HHD-5USB-BF-N Xenon XP 1952g 1D/2D Area Imager Scanner
The Honeywell 1962HHD-5USB-BF-N is a mid-range area imager scanner built for mixed-environment deployments where flexibility and durability matter more than bleeding-edge read speed. It decodes both 1D (linear) and 2D symbologies—EAN, UPC, Code 128, QR, Data Matrix—meaning you can deploy it across retail checkout, warehouse picking, shipping, and asset management without barcode-standard lockdown. The IP65 rating protects against splashes, dust, and light spray common in warehouse floors and outdoor loading zones. A 2.0 m (6.5 ft) drop rating signals ruggedness suitable for occasional rough handling, though not industrial-extreme environments. Dual Bluetooth 4.2 and USB connectivity lets you pair this scanner wirelessly to mobile devices on the floor or hardwire it to stationary POS terminals—no infrastructure overhaul required.
Key Features
- 1D/2D Area Imager decoding: Reads linear barcodes and 2D codes (QR, Data Matrix) in a single scan, so you're not locked into legacy barcode standards and can transition code types without equipment swaps.
- IP65 environmental rating: Protects against dust ingress and water spray, critical in warehouse receiving areas where hose-downs or dusty shelving is routine—skip this if your environment is climate-controlled office space only.
- 2.0 m drop rating: Withstands accidental drops from waist height; reduces equipment replacement costs in high-traffic scanning operations where handles break and units take hits.
- Wide working range (2.5–50.8 cm / 1–20 in): Accommodates both tight close-proximity checkout scanning and extended-distance inventory label reading—operators spend less time repositioning and focusing.
- Dual Bluetooth 4.2 + USB connectivity: Wireless freedom for mobile checkout carts and floor scanning; USB fallback for stationary POS terminals drawing continuous power from a docking station.
- Multi-symbology support: EAN, UPC, Code 128, QR Code, Data Matrix—future-proofs your asset base when retail or warehouse standards evolve without forcing scanner replacement.
- High first-pass read accuracy: Minimizes rescan delays during peak periods, directly reducing checkout line friction and inventory cycle-count time.
Integration & Compatibility
The 1962HHD-5USB-BF-N pairs with any system that accepts standard barcode input—point-of-sale platforms, warehouse management systems, mobile data collection apps, and asset management software. Bluetooth pairing eliminates the need for a dedicated cradle or cable run during floor deployment, while USB support integrates seamlessly with existing POS hardware without driver headaches. If you're operating a hybrid retail-warehouse environment where some scanning happens at fixed checkout stations and other scanning roams the floor, the flexibility of dual connectivity prevents you from buying separate hardware for each use case.
Typical Applications
- Point-of-sale checkout scanning and transaction capture
- Warehouse receiving, putaway, picking, and cycle-count operations
- Shipping and logistics label verification, proof-of-delivery documentation
- Manufacturing quality control and product serial number traceability
- Fixed-asset and IT equipment tracking programs
- Field service route scanning and mobile work order verification
When to Choose a Different Model
If your operation demands extreme ruggedness (frequent drops onto concrete, high-temperature exposure, or chemical splash resistance beyond IP65), or if you require specialized barcode symbologies (e.g., postal codes, pharmaceutical track-and-trace formats), consider a higher-rated variant within the Xenon XP family. Likewise, if your warehouse is fully climate-controlled and barcodes are pristine, the added durability here may be overbuilt—a general-purpose stationary scanner without drop or environmental ratings will cost less. Conversely, if you're operating mobile delivery or field routes where Bluetooth range or battery endurance is critical, evaluate paired mobile computers with integrated scanning rather than relying on external scanner battery life.
Frequently Asked Questions
Q: Is the 1962HHD-5USB-BF-N waterproof?
A: No. It is IP65 rated, meaning it resists water spray and dust but is not submersible. It will tolerate splash-down and wet floors, but not full immersion or sustained high-pressure wash-down. If submerged barcode scanning is required, specify IP67 or higher.
Q: Does the Honeywell 1962HHD-5USB-BF-N require a cradle or power supply to operate?
A: Via Bluetooth, it operates on internal battery with no cradle needed—you can scan wirelessly and tether to a charging dock only when needed. Via USB, it can draw power directly from a host device or USB power adapter, eliminating external power supply infrastructure.
Q: Can I upgrade the scanner firmware, and what symbologies are supported?
A: Firmware updates are managed through the host device or Honeywell support. The 1962HHD-5USB-BF-N supports standard 1D formats (EAN, UPC, Code 128) and major 2D formats (QR, Data Matrix). If you require specialized pharmaceutical, postal, or healthcare-specific barcodes, consult the datasheet or contact Honeywell technical support for codec compatibility confirmation.
Q: How does the 2.0 m drop rating compare to industrial-grade scanners?
A: The 2.0 m rating is mid-range—suitable for typical warehouse and retail drops from waist height. Industrial-grade scanners (rated 1.5–2.5 m from concrete) are generally more robust. The 1962HHD-5USB-BF-N is designed to survive occasional mishaps, not intentional impact testing.
Q: What's the effective scanning distance for dense barcodes vs. large-print QR codes?
A: The working range is 2.5–50.8 cm (1–20 in). Dense barcodes (high-module count) typically scan best in the lower half of that range; larger QR and Data Matrix codes can be read near the 50.8 cm limit. Exact distance depends on code size, contrast, and lighting—test with your actual barcode inventory before deployment.
Q: Is Honeywell technical support available for integration troubleshooting?
A: Honeywell offers standard technical support through their distribution channels. For integration questions specific to your POS or WMS platform, consult your system vendor's documentation for barcode scanner driver and compatibility requirements.
The Honeywell 1962HHD-5USB-BF-N sits in the practical middle tier of area imager scanners—not a premium device, but thoughtfully specified for environments where barcode density, dust, and occasional drops are real concerns. The IP65 rating and 2.0 m drop specification position it as the scanner you deploy to a warehouse or retail floor and don't lose sleep over. That said, extreme environments (chemical spray, sustained 40°C+ heat, or drop tests from overhead conveyor height) will demand a higher-rated alternative.
Technical Highlights:
- Dual Bluetooth 4.2 + USB connectivity: This is the real flexibility win. You can send a unit onto the floor as a handheld Bluetooth scanner without any infrastructure work, then plug the same unit into a POS terminal at checkout for continuous power and no re-pairing overhead. Most competitive scanners force you to choose one or the other.
- 2.5–50.8 cm working range: The upper bound (20 in) is long enough to read ceiling inventory labels and shelf tags from arm's reach; the lower bound (1 in) handles tight checkout gaps. This breadth eliminates repositioning time and reduces operator fatigue—concrete benefit in high-volume operations.
- 1D/2D decoding in one imager: No mode-switching, no barcode-type detection code. The scanner reads what it sees. When your organization transitions from UPC to QR or Data Matrix, this scanner doesn't become legacy overnight.
Deployment Considerations:
- The Bluetooth battery life is not infinite—confirm your duty cycle (scan frequency, idle time between charges) matches the internal battery capacity before committing Bluetooth units to all-day floor deployment. A docking cradle or USB tether during lunch hours is typical.
- IP65 does NOT mean drop-proof on every surface. Concrete and metal shelving are unforgiving; test real-world drop scenarios on your warehouse deck before assuming the 2.0 m rating translates to zero damage.
The 1962HHD-5USB-BF-N is the right choice for a warehouse or retail environment doing mixed 1D/2D scanning where you want to avoid dual-scanner inventory and can't justify premium durability pricing. Deploy it via USB at fixed stations and Bluetooth on carts, and you've solved a real fleet-management headache.
