Type:
Bullet
Features:
ColorVu
Features:
AI
Frame Rate:
Adjustable
Sensor Type:
1/1.8" Progressive Scan CMOS
Max. Resolution:
3840 × 2160
Min. Illumination:
0.0005 Lux color / 0.0001 Lux B/W
Shutter Time:
1 s to 1/100,000 s
Day & Night:
IR cut filter, Blue glass module (less ghost phenomenon)
Angle Adjustment:
Pan: 0° to 355°,tilt: 0° to 90°,rotate: 0° to 360°
Focal Length & FOV:
2.8-12mm, 99.8°-44.1° H-FOV
Focus:
Auto,Semi-auto,Manual
Iris Type:
P-iris
Aperture:
F1.0 to F1.2
DORI:
Wide: D 92m O 36.5m R 18.4m I 9.2m; Tele: D 204m O 81m R 40
Supplement Light Type:
Hybrid (IR and White Light)
Supplement Light Range:
Up to 50 m
Smart Supplement Light:
Yes
IR Wavelength:
850 nm
Model Specification:
Up to 4 models, Model type: detection model, classification model, mixed model (detection model and classification model)
Main Stream:
3840×2160 @ 25fps
Sub-Stream:
704×576 @ 25fps
Third Stream:
1920×1080 @ 25fps
Fourth Stream:
25-30 fps, 704×576 to 640×480
Fifth Stream:
25-30 fps (704×576, 640×480)
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264, +more
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Baseline Profile,Main Profile,High Profile
H.265 Type:
Main Profile
Bit Rate Control:
CBR,VBR
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
4 fixed regions for each stream
Target Cropping:
Yes
Audio Type:
Mono sound
Audio Compression:
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate:
64 Kbps (G.711), 16 Kbps (G.722.1), 32-192 Kbps (MP2L2
Audio Sampling Rate:
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering:
Yes
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, SRTP, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, ARP, WebSocket, WebSockets
Simultaneous Live View:
Up to 20 channels
API:
ONVIF Profile S/G/T/M, ISAPI, SDK, ISUP
User/Host:
32 users, 3 levels
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Inter
Network Storage:
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client:
iVMS-4200,Hik-Connect,Hik-Central
Web Browser:
Plug-in required live view: IE 10, IE 11, +more
Image Parameters Switch:
Yes
Image Settings:
Saturation,brightness,contrast,sharpness,white balance,AGC,adjustable by client software or web browser
Day/Night Switch:
Day,Night,Auto,Schedule,Alarm Trigger,Video Trigger
Wide Dynamic Range (WDR:
140 dB
Image Enhancement:
BLC,HLC,3D DNR,Defog
Privacy Mask:
8 programmable polygon privacy masks
SNR:
≥ 52 dB
Picture Overlay:
Logo overlay, 128×128 bmp
Image Stabilization:
EIS
Video Outputs:
1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)
Ethernet Interface:
1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
On-Board Storage:
microSD/microSDHC/microSDXC, up to 1 TB
Alarm:
2 inputs, 2 outputs (max. 24 VDC, 1 A)
Audio Support:
1 input (line in), 3.5 mm connector, three-contact, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output (line out), 3.5 mm connector, three-contact, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω
RS-485:
1 RS-485 Half Duplex
Reset Key:
Yes
Power Output:
12 VDC, max. 100 mA
Basic Event:
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,video quality diagnosis,exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error),vibrat
Smart Event:
scene change detection,audio exception detection,defocus detection
Linkage:
FTP/NAS/Card, Email, Alarm, Recording, Capture
Multi-Target-Type Detection:
Human/face/vehicle detection
Face Capture:
120 faces, 40 pics/frame, 10 pics/sec
Face Comparison:
10 libraries, 30,000 faces each
People Counting:
Multi-dimensional people counting with flow analytics
Queue Management:
Supports up to 8 detection regions, and independent arming schedule and linkage method;Supports 2 detection modes: regional people queuing-up, waiting time detection;Generates reports to compare the efficiency of different queuing-ups and display the
Heat Map:
A graphic description of visits (by calculating amount of people or amount of dwell time) in a configured area., Two report types are available, space heat map and time heat map line chart.
Hard Hat Detection:
Detects 30 targets, 4 shield regions
Perimeter Protection:
Line crossing, intrusion, region entrance/exit
Metadata:
Intrusion detection, line crossing, face capture
Regional People Counting:
8 regions, 3 detection modes
On/Off Duty Detection:
8 regions, 2 detection modes
Power Type:
PoE
Material:
Aluminum alloy body
Dimension:
Ø140 mm × 378.4 mm (Ø5.5" × 14.9")
Package Dimension:
425 mm × 190 mm × 180 mm (16.7" × 7.5" × 7.1")
Weight:
Approx. 2280 g (5.0 lb.)
With Package Weight:
Approx. 3370 g (7.4 lb.)
Storage Conditions:
-40°C to 60°C, 95% RH non-condensing
Startup And Operating Conditions:
-40°C to 60°C
Language:
33 languages: English, Russian, Estonian, Bulgarian, +more
General Function:
Heartbeat,anti-banding,one-key reset,mirror,password protection,flash log
Heater:
Yes
Demist:
Yes
Device Management:
Alarm box DS-FM2466 expansion (6 in/6 out)
EMC:
FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015
Safety:
UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1
Environment Rating:
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
Protection:
IP67: IEC 60529-2013,IK10: IEC 62262:2002
Anti-Corrosion Protection:
-Y: NEMA 4X (NEMA 250-2018)
Automotive And Railway:
EN50121-4
Other:
PVC FREE
Product Type:
Bullet
Connectivity:
Wired
IP Rating:
IP67
Resolution:
8MP
Night Vision:
Color
Housing Color:
White
Warranty:
5-year warranty
