Type:
Bullet
Features:
Weatherproof
Features:
Night Vision
Frame Rate:
Variable
Sensor Type:
1/1.8" Progressive Scan CMOS
Max. Resolution:
2688 × 1520
Min. Illumination:
0.0005 Lux color
Shutter Time:
1/3 s to 1/100,000 s
Angle Adjustment:
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Lens Type:
Fixed focal lens, 2.8, 4, and 6 mm optional
Focal Length & FOV:
2.8mm (112° H), 4mm (95° H), 6mm (58° H)
Lens Mount:
M16
Iris Type:
Fixed
Aperture:
F1.0
Depth Of Field:
2.8 mm, 2.5 m to ∞;4 mm, 3.5 m to ∞;6 mm, 7.5 m to ∞
DORI:
2.8mm@58m, 4mm@77m, 6mm@115m
Supplement Light Type:
White Light
Supplement Light Range:
40 m
Smart Supplement Light:
Yes
Main Stream:
2688×1520 @ 25fps
Sub-Stream:
1280×720 @ 25fps
Third Stream:
1920×1080 @ 10fps
Video Compression:
Main stream: H.265/H.264/H.265+/H.264+, +more
Video Bit Rate:
32 Kbps to 8 Mbps
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main Profile
Bit Rate Control:
CBR/VBR
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
1 fixed region for main stream and sub-stream
Audio Compression:
-U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate:
8-320 Kbps
Audio Sampling Rate:
-U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering:
-U: Yes
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets
Simultaneous Live View:
Up to 6 channels
API:
ONVIF, ISAPI, SDK
User/Host:
32 users, 3 levels
Security:
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage:
MicroSD/microSDHC/microSDXC card (512 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR);Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client:
iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Plug-in required live view: IE 10, IE 11, +more
Image Parameters Switch:
Yes
Image Settings:
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch:
Auto, Schedule
Wide Dynamic Range (WDR:
130 dB
SNR:
≥ 52 dB
Image Enhancement:
BLC, HLC, 3D DNR
Ethernet Interface:
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage:
microSD card, up to 512 GB
Built-In Microphone:
-U: Yes
Reset Key:
Yes
Basic Event:
Motion detection (human and vehicle targets classification), video tampering alarm, exception
Smart Event:
Line crossing detection, intrusion detection, region entrance detection, region exiting detection;Scene change detection
Linkage:
Alarm Outputs: NAS, Email, FTP, Recording, Capture
Face Capture:
Yes
Power Type:
PoE
Dimension:
215.2 mm × 78.8 mm × 78.6 mm (8.5" × 3.1" × 3.1")
Package Dimension:
315 mm × 137 mm × 141 mm (12.4" × 5.4" × 5.6")
Weight:
Approx. 695 g (1.5 lb.)
With Package Weight:
Approx. 1090 g (2.4 lb.)
Storage Conditions:
-30°C to 60°C, ≤95% humidity
Startup And Operating Conditions:
-30°C to 60°C
Language:
33 languages, English, Russian, Estonian, Bulgarian, +more
General Function:
Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
EMC:
FCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
Safety:
UL (UL 60950-1); CB (IEC 60950-1: 2005 + Am 1: 2009 + Am 2: 2013, IEC 62368-1: 2014); CE-LVD (EN 60950-1: 2005 + Am 1: 2009 + Am 2: 2013, IEC 62368-1: 2014); LOA (IEC/EN 60950-1)
Environment Rating:
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection:
IP67 (IEC 60529-2013)
Product Type:
Bullet
Connectivity:
Wired
Resolution:
4MP
Night Vision:
IR
Housing Color:
White
Warranty:
5-year warranty
eol:
true
