Type:
Dome
Features:
ColorVu
Features:
Built-in Light
Frame Rate:
30 fps
Sensor Type:
1/1.8" Progressive Scan CMOS
Max. Resolution:
3840 × 2160
Min. Illumination:
0.0008 Lux color
Shutter Time:
1/3 s to 1/100,000 s
Day & Night:
24/7 color imaging
Angle Adjustment:
Pan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°
Lens Type:
Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV:
2.8mm (109° H) / 4mm (93° H)
Lens Mount:
M16
Iris Type:
Fixed
Aperture:
F1.0
Depth Of Field:
2.8 mm: 3.1 m to ∞;4 mm: 3.5 m to ∞
DORI:
2.8 mm, D: 84 m, O: 33 m, R: 16 m, I: 8 m;4 mm, D: 102 m, O: 40 m, R: 20 m, I: 10 m
Supplement Light Type:
White Light
Supplement Light Range:
Up to 30 m
Smart Supplement Light:
Yes
Main Stream:
3840×2160 @ 25fps
Sub-Stream:
1280×720 @ 25fps
Third Stream:
1920×1080 @ 10fps
Video Compression:
Main stream: H.265+/H.265/H.264+/H.264, +more
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Baseline Profile,Main Profile,High Profile
H.265 Type:
Main Profile
Bit Rate Control:
CBR,VBR
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
1 fixed region(s) for main stream and sub-stream
Audio Type:
-SU: Mono sound
Audio Compression:
-SU: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate:
64 Kbps (G.711) / 16-320 Kbps (MP3)
Audio Sampling Rate:
-SU: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering:
-SU: Yes
Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
Simultaneous Live View:
Up to 6 channels
API:
ONVIF Profile S/G/T, ISAPI, SDK, ISUP
User/Host:
32 users, 3 levels
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Inter
Network Storage:
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client:
iVMS-4200,iVMS-5200,Hik-Connect
Web Browser:
Plug-in required live view: IE 10, IE 11, +more
Image Parameters Switch:
Yes
Image Settings:
Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Day/Night Switch:
Day,Night,Auto,Schedule
Wide Dynamic Range (WDR:
130 dB
SNR:
≥ 52 dB
Image Enhancement:
BLC,HLC,3D DNR
Privacy Mask:
4 regions of privacy mask
Ethernet Interface:
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage:
MicroSD/SDHC/SDXC up to 512GB
Built-In Microphone:
-SU: Yes
Audio Support:
-SU: 1 input(s) (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output(s) (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, int
Alarm:
-SU: 1 input(s), 1 output(s) (max. 12 VDC, 30 mA)
Reset Key:
Yes
Basic Event:
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Smart Event:
Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)), scene change detection
Linkage:
FTP/NAS/memory card/email/alarm
Face Capture:
Yes
Power Type:
PoE
Material:
Metal
Dimension:
Ø121.5 mm × 97.6 mm (Ø4.8 × 3.8)"""
Package Dimension:
150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")
Weight:
Approx. 540 g (1.2 lb.)
With Package Weight:
Approx. 735 g (1.6 lb.)
Language:
33 languages: English, Russian, Estonian, Bulgarian, +more
Storage Conditions:
-30°C to 60°C, ≤95% RH non-condensing
General Function:
Heartbeat,anti-banding,mirror,flash log,password reset via email,pixel counter,password protection,one-key reset,three streams
Startup And Operating Conditions:
-30°C to 60°C
EMC:
FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7
Safety:
UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, LOA: IEC/EN 60950-1
Environment Rating:
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
Protection:
IP67: IEC 60529-2013,IK10: IEC 62262:2002
Product Type:
Dome
Connectivity:
Wired
Night Vision:
Color
PoE Class:
3
Form Factor:
Dome
IP Rating:
IP67
Vandal Rating:
IK10
Max Channels:
6
Resolution:
8MP
Day/Night:
Yes
Storage Support:
microSD
Outdoor Ready:
Yes
HTTPS Encryption:
Yes
WDR:
WDR
Image Sensor Size:
1/1.8"
Horizontal Fov:
109°
Vertical Fov:
59°
Wide Dynamic Range:
WDR
Housing Color:
White
Warranty:
5-year warranty
