Panduit HD F 12F Mpo-lc OM4 UIL MA Pols PK1 - FHCZA-12-GRAS

Panduit FHCZA-12-GRAS Concise Descriptor

Overview

The Panduit FHCZA-12-GRAS is a 12-fiber MTP/MPO to LC OM4 connector assembly designed for high-density fiber optic deployments. It facilitates efficient transitions from MTP/MPO trunk infrastructure to LC duplex patch panels or equipment, crucial for maximizing port density in data centers and enterprise backbones. This assembly supports 40GbE and 100GbE applications where OM4 fiber is specified for its enhanced bandwidth and reach.

Compatibility

This connector assembly is engineered for use with standard MTP/MPO trunk cables and LC duplex patch cords. It is compatible with Panduit's Quick-Access™ fiber optic systems and other infrastructure components that utilize MTP/MPO and LC connectivity. It is suitable for OM4 fiber optic networks, commonly deployed in 40GBASE-SR4, 100GBASE-SR4, and future higher-speed Ethernet standards.

Installation Notes

Ensure proper handling of fiber optic connectors to avoid contamination. Use appropriate cleaning tools before mating connectors. The push-pull tab on the MTP/MPO connector facilitates secure engagement and disengagement. Verify correct polarity (Type A, B, or C) based on your network design requirements when connecting to trunk cables.

What's in the Box

• 1x FHCZA-12-GRAS 12-Fiber MTP/MPO to LC OM4 Connector Assembly
