Hanwha XNB-H6282B 2MP Network Bandit Barrier Camera Kit

Hanwha XNB-H6282B 2MP Network Bandit Barrier Camera Kit

The Hanwha XNB-H6282B is a specialized 2MP network camera designed for high-security counter and teller applications in banking and retail environments. This complete kit combines a compact IP camera with an innovative adjustable bandit barrier housing that extends from 175mm to 737mm, enabling flexible installation on counters, partitions, and transaction windows. The system delivers professional-grade surveillance with seamless integration and overt security presence.

Key Features

• 2MP resolution (1920×1080) at up to 60fps for smooth, detailed video capture
• 2.8mm fixed lens with 107.4° wide-angle field of view
• Adjustable bandit barrier housing with height range of 175–737mm
• extremeWDR technology (120dB) for clear imaging in high-contrast lighting
• Auto electrical day/night switching with backlight compensation (BLC, HLC, SSDR)
• Advanced analytics including motion detection, face detection, and tampering alerts
• H.265/H.264/MJPEG codec support with WiseStream II bandwidth optimization
• Built-in microSD card slot (up to 1TB) for local edge storage and backup
• Bi-directional audio with selectable microphone or line-in input
• PoE (IEEE 802.3af) and 12VDC power options
• 8-meter pre-installed cable for rapid deployment
• IP Address filtering, 802.1X authentication, and HTTPS/SSL encryption

Technical Specifications

Video & Imaging: Supports resolutions from 320×240 to 1920×1080 with frame rates up to 60fps (H.265/H.264) or 30fps (MJPEG). Digital image stabilization, lens distortion correction (LDC), and defog technology ensure clarity in challenging conditions. Privacy masking includes 32 quadrangle zones with multiple color options and mosaic effects.

Analytics & Intelligence: Built-in analytics deliver defocus detection, motion detection (8-zone polygonal), tampering detection, audio detection, face detection, and virtual area/line crossing analysis. Business intelligence features include people counting, queue management, and heatmap generation.

Connectivity & Storage: Gigabit Ethernet with ONVIF Profile S/G/T compliance ensures broad integration. Supports RTSP, HTTP/HTTPS, TCP/IP, and UDP streaming with unicast (20 users) and multicast capabilities. Edge storage via microSD/SDHC/SDXC cards up to 1TB; NAS recording on event triggers.

Power & Reliability: Low power consumption (6.9W typical with PoE; 5.5W with 12VDC) with redundancy failover support. Operating temperature range -10°C to +55°C suits diverse indoor environments.

Applications

Ideal for bank teller lines, retail checkout counters, transaction windows, and customer service desks where overt security presence and detailed facial recognition are critical. The adjustable housing blends seamlessly into counter infrastructure while maintaining unobstructed sightlines for facial capture and behavioral analysis.

James Everett

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

The XNB-H6282B addresses a specific market gap: transaction environment surveillance requiring both deterrence and forensic detail. The bandit barrier form factor is engineered for purpose—the adjustable height (175–737mm) accommodates varying counter heights and sightlines without requiring custom mounting. The 107.4° field of view with 2MP resolution balances wide coverage with sufficient detail for facial identification at typical transaction distances (1–3 meters).

WiseStream II codec optimization is particularly valuable in high-concurrency environments; the camera supports 10 simultaneous streaming profiles, enabling simultaneous retail operations monitoring, security operations center feeds, and forensic review without network saturation. The 120dB extremeWDR handles the common retail challenge of backlighting from storefront windows or bright outdoor areas behind customers.

Audio integration (bidirectional) is a practical addition for environments using the camera for two-way communication with customers or staff. Redundancy failover and NAS recording on alarm events ensure business continuity during network interruptions—critical for retail operations that cannot tolerate surveillance gaps.

The included 8-meter cable accelerates deployment, eliminating custom cable runs in retrofit scenarios. ONVIF compliance guarantees vendor independence; systems can integrate with Hanwha NVRs or third-party management platforms. For security managers evaluating counter surveillance, the XNB-H6282B represents a purpose-built solution that avoids over-specification while delivering the specific imaging and presence requirements of transaction environments.
