Imaging Device:
Uncooled micro bolometer (Spectral range: 8~14㎛)
Resolution:
768×576
Max. Framerate:
8fps
Thermal Sensitivity (NETD:
＜30mK
Pixel Size:
17㎛
Video Out:
USB: Micro USB Type B, 768x576 for installation
Focal Length (Zoom Ratio:
4.4mm fixed focal
Max. Aperture Ratio:
F1.0
Angular Field of View:
H: 90°, V: 65.3°
Min. Object Distance:
0.6m
Focus Control:
fixed
Pan / Tilt / Rotate Range:
0°~350° / 0°~90° / 0°~350°
Camera Title:
Displayed up to 85 characters
Motion Detection:
8ea, 8point polygonal zones
Privacy Masking:
6ea, Rectangle zones; - color : Grey, Black, White
Video Rotation:
Flip, Mirror, Hallway view(90˚/270˚)
Analytics:
Classified object type: Person/Vehicle; Support BestShot; Analytics events based on AI engine; - WiseMD, Object detection, Virtual line*(Crossing/Direction), Virtual area*(Loitering/Intrusion/Enter/Exit); Analytics events; - Motion detection, Tamperi
Business Intelligence:
Support (Temperature data)
Serial Interface:
RS-485
Alarm Inputs/Outputs:
2 configurable I/O ports
Alarm Triggers:
Analytics, Network disconnect, Alarm input, Time schedule, MQTT subscription
Alarm Events:
When alarm trigger occurred; - File upload(image): e-mail/FTP; - Notification: e-mail; - Recording: SD/SDHC/SDXC or NAS recording at event triggers; - Alarm output; - Handover: PTZ preset; - MQTT: publication
Audio In:
Selectable(mic in/line in)
Audio Out:
Line out
Color Palettes:
Whitehot, Blackhot, Rainbow, Sepia, Red, Iron, Custom
Temperature Detect Range:
-40°C~550°C(-40°F~1022°F)
Temperature Accuracy:
±2°C (below 150°C), ±15% (above 150°C)
Temperature Detection:
10 Polygonal ROI zones, whole FoV area
Additional:
Spot temp reading, ROI monitoring
Ethernet:
Metal shielded RJ-45(10/100/1000BASE-T)
Video Compression:
H.265/H.264: Main/Baseline/High, MJPEG
Audio Compression:
G.711 u-law / G.726 Selectable, G.726(ADPCM) 8KHz, +more
Smart Codec:
WiseStream II, WiseStream III
Bitrate Control:
H.264/H.265: CBR or VBR; MJPEG: VBR
Streaming:
Unicast(20 users) / Multicast; Multiple streaming(Up to 10 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP (TCP, UDP Unicast), MQTT
Application Programming Interface:
ONVIF Profile S/G/T/M; SUNAPI; Wisenet
OS / Firmware Protect:
Secure boot, Signed firmware, Firmware encryption
User authentication:
Digest Authentication, Prevent brute-force attack
Network authentication:
802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
Secure Communication:
HTTPS, SRTP, WSS(Websocket secure)
Access Control:
Access control based on IP address
Data Protect:
Authentication & ZIP encryption
Audit:
User Access/System/Event log management
Device ID:
Device Certificate(Hanwha Private Root CA)
Secure Storage:
TPM(Trusted platform module), SDcard partition encrypt
Security Certificate:
TPM with FIPS 140-2 level 2
Webpage Language:
English, Korean, Chinese, French, Italian, +more
Edge Storage:
Micro SD/SDHC/SDXC 1slot Max. 1TB
RAM:
2GB RAM, 512MB Flash
Operating Temperature / Humidity:
-40°C~+60°C(-40°F~+140°F) / 0~95% RH(non-condensing)
Storage Temperature / Humidity:
-50°C~+60°C(-58°F~+140°F) / Less than 95% RH
Certification:
IP66, IK10, NEMA4X
Input Voltage:
PoE(IEEE802.3af, Class3), 12VDC
Power (Max:
10.8W
Color / Material:
White / Aluminum + PC
RAL Code:
RAL9003
Product Dimensions / Weight:
ø93.8x233.5mm(ø3.69x/9.19"), 1700g(3.75 lb)
Compatible Conduit hole / Gangbox:
Conduit hole : SBP-060BA(Sold seperately); Gangbox : single, double, 4" octagon, 4" square
Backbox:
Included
Pole Mount:
SBD-180PMW, SBP-300PMW2
Corner Mount:
SBP-300KMW1
Cabinet:
SBP-300NBW
Conduit Adaptor:
SBP-060BA
EMC:
EN 55032:2015/A11:2020; EN 50130-4:2011/A1:2014; EN 61000-3-2:2014; EN 61000-3-3:2013; FCC - 47 CFR Part 15, Subpart B Class A; FCC - IC Regulation ICES 003 Issue 7; RCM - EN IEC 63000:2018 Class A; VCCI - EN IEC 63000:2018 Class A; KS - KS C 9832:20
Safety:
UL/CSA 62368-1
Environment Rating:
ROHS - EN IEC 63000:2018; IK10 - KS C IEC 62262: 2005; IP66 - IEC 60529:1989 +A1:1999+A2:2013; NEMA4X - NEMA 250-2014
Ver:
1.0
Product Type:
Bullet
Housing Color:
White
Poe Power:
PoE (802.3af)
Compression:
H.265; H.264; MJPEG
Onvif:
Yes
Audio:
Audio input
Lens Focal Length:
4.4 mm
Mount Type:
Wall; Ceiling; Pole; Corner
Camera:
Title Displayed up to 85 characters
Ethernet Rate:
Metal shielded RJ-45(10/100/1000BASE-T)
Application:
Programming Interface ONVIF Profile S/G/T/M
Operating System:
/ Firmware Protect Secure boot, Signed firmware, Firmware encryption
Memory:
2GB RAM, 512MB Flash
Operating Temp:
/ Humidity -40°C~+60°C(-40°F~+140°F) / 0~95% RH(non-condensing)
Storage:
Temperature / Humidity -50°C~+60°C(-58°F~+140°F) / Less than 95% RH
Certifications:
& Standards
Nema Rating:
4X - NEMA 250-2014
Resolution Pixels:
384x288
Frame Rate:
8fps
