Imaging Device:
1/2.8" CMOS
Resolution:
1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
Max. Framerate:
H.265/H.264: Max. 60fps/50fps(60Hz/50Hz) MJPEG: Max. 30fps/25fps(60Hz/50Hz)
Min. Illumination:
Color: 0.05Lux(F1.6, 1/30sec, 30IRE) BW: 0.005Lux(F1.6, 1/30sec, 30IRE), 0Lux(IR LED On)
Focal Length (Zoom Ratio:
4.44~142.6mm(32x) zoom (digital 32x, total 1024x zoom)
Max. Aperture Ratio:
F1.6(Wide)~F4.4(Tele)
Angular Field of View:
H: 64.66°(Wide)~2.29°(Tele) V: 38.08°(Wide)~1.30°(Tele)
Min. Object Distance:
Wide: 1.5m(4.92ft) / Tele: 2m(6.56ft)
Focus Control:
Oneshot AF, Focus save
Lens Type:
DC auto iris
Pan Range:
360° Endless
Pan Speed:
Preset: 700°/sec, Manual: 0.024°/sec~250°/sec
Tilt Range:
110°(0°~110°)
Tilt Speed:
Preset: 300°/sec, Manual: 0.024°/sec~250°/sec
Sequence:
Preset(300ea), Swing, Group(6ea), Trace, Tour, Auto Run, Schedule
Preset Accuracy:
±0.2°
Camera Title:
Displayed up to 85 characters
Direction Indicator:
Support
Day & Night:
Auto(ICR)
Backlight Compensation:
BLC, HLC, WDR, SSDR
Wide Dynamic Range:
120dB
Digital Noise Reduction:
SSNRⅤ
Digital Image Stabilization:
Support(built-in gyro sensor)
Defog:
Support
Motion Detection:
8ea, 8point polygonal zones
Privacy Masking:
32ea, 4point quadrangle zones - Color: Grey/Green/Red/Blue/Black/White - Solid/Mosaic
Gain Control:
Low / Middle / High
White Balance:
ATW / AWC / Manual / Indoor / Outdoor / Mercury / Sodium
LDC:
None
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (2~1/12,000sec)
Digital PTZ:
None
Video Rotation:
Flip, Mirror
Analytics:
Analytics events - Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line * Audio detection(Via optional I/O box SPM-4210)
Light Type:
IR LED (850nm)
IR Viewable Length:
100m(328.08ft)
Auto Tracking:
Support
Ethernet:
Metal shielded RJ-45(10/100BASE-T)
Video Compression:
H.265/H.264: Main/High, MJPEG
Smart Codec:
Manual(5ea area), WiseStreamⅡ
Video Quality Adjustment:
H.264/H.265: Target bitrate level control MJPEG: Target bitrate level control
Bitrate Control:
H.264/H.265: CBR or VBR MJPEG: VBR
Streaming:
Unicast(20 users) / Multicast Multiple streaming(Up to 10 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast), NTCIP1205
Application Programming Interface:
ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform
OS / Firmware Protect:
Firmware encryption
User authentication:
Digest Authentication, Privent brute-force attack
Network authentication:
802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
Secure Communication:
HTTPS, SRTP, WSS(Websocket secure)
Access Control:
IP address filtering
Data Protect:
Authentication information encryption, ZIP compression encryption
Audit:
User Access/System/Event log
Device ID:
Device Certificate(Hanwha Techwin Root CA, pre-installed)
Webpage Language:
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Edge Storage:
Micro SD/SDHC/SDXC 1slot Max. 256GB
Memory:
1GB RAM, 256MB Flash
Operating Temperature / Humidity:
-35°C~+55°(-31°F ~ +131°F) * Start up should be done at above -30°C 0~95% RH(non-condensing)
Storage Temperature / Humidity:
-50°C~+60°C(-58°F~+140°F) / 0~95% RH
Certification:
IP66, IK10, NEMA4X
Input Voltage:
PoE+(IEEE802.3at, Class4)
Power Consumption:
PoE+: Max. 25.5W, typical 14.7W
Color / Material:
Body : White / Aluminum Head : Black / Polycarbontate Hard-coated dome
RAL Code:
RAL9003
Product Dimensions / Weight:
ø158x293.3mm(ø6.22x11.55"), 3100g(6.83lb)
Hanging Mount (Dome:
SBP-156HMW
Ceiling Mount (Assy:
SBP-156CMW, SBP-300CMTS, SBP-300CMW1/900CMW, SBP-150CMI/300CMI
Wall Mount:
SBP-156WMW, SBP-390WMW2
Pole Mount:
SBP-300PMW2
Parapet Mount:
SBP-156LMW, SBP-300LMW
Corner Mount:
SBP-156KMW, SBP-300KMW1
Cabinet:
SBP-300NBW
EMC:
FCC 47 CFR 15 Subpart B Class A IC Regulation ICES-003 Issue 7 Class A CE/UKCA - EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3 VCCI CISPR 32 Class A RCM AS/NZS CISPR 32 Class A
Safety:
UL 62368-1, CAN/CSA C22.2 NO. 62368-1 IEC/EN 62471
Environment:
IEC/EN 63000 IEC/EN 60529 IP66, IEC/EN 62262 IK10
DORI Detect (25PPM/ 8PPF:
Wide: 60.7m(199.1ft) / Tele: 1921.3m(6303.4ft)
DORI Observe (63PPM/ 19PPF:
Wide: 24.3m(79.6ft) / Tele: 768.5m(2521.4ft)
DORI Recognize (125PPM/ 38PPF:
Wide: 12.1m(39.8ft) / Tele: 384.3m(1260.7ft)
DORI Identify (250PPM/ 76PPF:
Wide: 6.1m(19.9ft) / Tele: 192.1m(630.3ft)
Ver:
2310
