Hanwha HCV-7070RA 4MP Outdoor Dome Camera

Hanwha HCV-7070RA 4MP Outdoor Dome Camera

The Hanwha HCV-7070RA is a robust 4MP outdoor dome camera engineered for professional surveillance deployments requiring high-resolution imaging, extended night vision, and reliable coaxial transmission over extended distances. Built on a 1/3" 4MP CMOS sensor with 2688×1520 effective pixels, this camera delivers QHD video at 2560×1440 resolution (30fps NTSC / 25fps PAL) with exceptional clarity across diverse lighting conditions and weather environments.

Key Features

• 4MP resolution with QHD video output at 2560×1440 @ 30fps
• 3.2–10mm manual varifocal lens with 3.1× optical zoom
• 0.16 Lux color sensitivity; 0 Lux infrared with 30m IR viewing range
• IP66 and IK10 certifications for extreme weather and vandal resistance
• Dual power support: 24VAC or 12VDC input
• Coaxial transmission up to 500m on standard 5C2V cable
• Auto day/night switching with ICR (Infrared Cut filter Removal)
• Four-zone motion detection with privacy masking
• Compact aluminum dome design, 715g with mounting accessories

Technical Highlights

Imaging & Optics: The F1.6 maximum aperture and wide angular field of view (93.48° horizontal at wide focal length) enable comprehensive coverage of expansive outdoor areas. Manual focus control and DC auto iris lens deliver precision in fixed deployment scenarios. The minimum object distance of 0.5m supports close-range monitoring applications.

Low-Light Performance: Advanced ICR day/night technology combined with 30m IR LED range ensures reliable 24/7 surveillance during darkness. 2D digital noise reduction (2DDNR) minimizes video grain in low-illumination environments while maintaining detail.

Enhanced Imaging: User-adjustable backlight compensation options (BLC, HLC, DWDR) handle challenging contrast scenarios. Multiple white balance modes (ATW, AWC, Manual, Indoor, Outdoor) and electronic shutter speeds (1/30 to 1/12,000sec) provide adaptive image quality across varying conditions.

Durability & Deployment: IP66 rating protects against high-pressure water jets and dust ingress; IK10 rating withstands severe impact. Operating temperature range of -10°C to +55°C ensures reliable performance in harsh climates. Pan/tilt/rotate capabilities (350°/63°/355°) and 0˚–355˚ video rotation enable flexible installation orientations.

Coaxial Integration: Supports ACP (AHD Coax Protocol) for digital transmission and Pelco-C (Coaxitron) for analog CVBS, enabling seamless integration with existing coaxial infrastructure. Video transmission capability extends to 500m, reducing infrastructure costs in large-scale deployments.

Jerry Tildsen

The HCV-7070RA targets mid-to-large outdoor surveillance installations where coaxial transmission and extended cable runs are practical or cost-effective. The 4MP sensor and QHD output balance resolution with reasonable bandwidth consumption and storage requirements. Manual varifocal optics require on-site focus adjustment but eliminate motorized lens complexity and power draw.

The 30m IR range and 0.16 Lux sensitivity adequately cover typical perimeter security scenarios, though users requiring ultra-wide area coverage should evaluate multi-camera deployments. IP66/IK10 ratings and aluminum construction justify outdoor placement without supplemental housing. Power consumption of 5.8W maximum and dual voltage input (24VAC/12VDC) offer flexibility in legacy or modern power infrastructure.

The four-zone motion detection with privacy masking supports business compliance requirements. This camera suits parking lots, building exteriors, entrance areas, and utility site monitoring where coaxial backbone systems remain the transmission standard.

Applications

• Building exterior and perimeter surveillance
• Parking facility monitoring
• Entrance and exit point coverage
• Utility and industrial site monitoring
• Legacy coaxial system upgrades
• Extended-distance surveillance deployments
