Vertiv GXT5-1000LVRT2UXLTAAN 1000VA Online Double-Conversion Rack/Tower UPS
Overview
The GXT5-1000LVRT2UXLTAAN is a 1000VA / 1000W online double-conversion UPS from Vertiv's Vertiv Liebert GXT5 line — a TAA-compliant, rack/tower convertible unit built for critical infrastructure where utility power quality cannot be trusted. Unlike standby or line-interactive topologies, the double-conversion architecture regenerates the output from scratch on every cycle, meaning downstream equipment sees a clean sine wave regardless of what's happening on the input side. That matters in environments where servers, NVRs, or network switches would otherwise absorb voltage sags, surges, frequency drift, or partial outages. The GXT5-1000LVRT2UXLTAAN (often searched as GXT5 1000LVRT2UXLTAAN) ships in a compact 2U chassis that converts between rack and tower orientation without tools, and its gravity-sensing LCD rotates the display accordingly.
Key Features
- Online Double-Conversion Topology: The UPS continuously inverts utility power and rebuilds a clean 120V AC output — there is zero transfer time to battery when utility power fails. For NVRs and recording servers where even a 4–8ms transfer gap can corrupt a write, this is the architecture that eliminates the risk entirely.
- 1000VA / 1000W Power Rating (Unity Power Factor): At 1.0 power factor, the GXT5 delivers its full 1000W — no de-rating for modern switching power supplies that draw near-unity loads. You can plan rack power budgets directly against the 1000W nameplate without discount.
- Up to 98% Efficiency in Active ECO Mode: Standard on-line mode runs at up to 95% efficiency. Active ECO mode pushes that to 98% by routing through the inverter only when needed, cutting heat output and operating cost — useful in always-on deployments where the UPS runs loaded 24/7.
- Configurable Output Voltage: Output is selectable at 110, 115, 120, or 125VAC (±3%) without hardware changes. If downstream equipment has specific voltage sensitivity — some older analog video equipment or legacy access control panels — you can dial it in at commissioning rather than adding a separate regulator.
- Six NEMA 5-15R Outlets (4 Programmable): Four individually programmable receptacles let you assign load-shedding sequences or staggered restart order — important for surveillance systems where the NVR should power on before cameras complete their boot cycle. The two non-programmable outlets provide always-on power for critical devices.
- Wide Input Voltage Window (60–150V): The 60–150V input range means the unit rides through extreme utility fluctuations on battery reserve only when necessary, extending runtime and battery life in areas with marginal power infrastructure.
- Colored Gravity-Sensing LCD: The control panel detects physical orientation and rotates its display — whether the unit is racked horizontally or standing vertically as a tower. This eliminates the usual annoyance of upside-down status reads after a rack reconfiguration.
- ENERGY STAR 2.0 Certified: The ENERGY STAR 2.0 certification and RoHS2 / REACH compliance are meaningful for government and enterprise procurement teams facing sustainability requirements or green-building rating systems.
- Flexible Communications (USB, RS232, RS485, IntelliSlot): USB and serial ports (RS232, RS485) are on-board for local management. The optional Liebert IntelliSlot RDU120 card adds SNMP and web management — enabling integration into DCIM, BMS, or centralized monitoring platforms without replacing the UPS hardware.
- TAA Compliance: The TAA designation means this unit is eligible for U.S. federal, state, and municipal procurement vehicles that require Trade Agreements Act compliance — a hard requirement for GSA Schedule, SEWP, and many state cooperative contracts.
Integration and Compatibility
The GXT5-1000LVRT2UXLTAAN integrates with building management systems and IT monitoring platforms via its RS232/RS485 serial ports out of the box. Adding the optional Vertiv Liebert IntelliSlot RDU120 card enables full SNMP traps and a built-in web interface, making it compatible with most enterprise NMS platforms (SolarWinds, PRTG, Nagios) and Vertiv's own Liebert Nform or Trellis monitoring software. The USB port supports direct connection to a server or workstation running UPS management software for graceful OS shutdown on battery events. The external battery connector allows the runtime envelope to be extended with a compatible external battery cabinet — useful in surveillance or access control applications where extended outage ride-through is a site requirement. Listings include UL 1778 4th edition and CSA 22.2 No. 107.1, satisfying electrical code compliance requirements for power protection equipment in commercial and government facilities.
Frequently Asked Questions
Q: Is the GXT5-1000LVRT2UXLTAAN TAA compliant for government purchasing?
A: Yes. The GXT5-1000LVRT2UXLTAAN carries TAA (Trade Agreements Act) compliance, making it eligible for GSA Schedule, SEWP, and other U.S. federal and state cooperative purchasing contracts that require domestically or TAA-country sourced products.
Q: What is the difference between on-line mode and Active ECO mode on the GXT5?
A: In on-line (double-conversion) mode, the UPS continuously regenerates output power through the inverter at up to 95% efficiency. Active ECO mode routes power through a bypass path under stable utility conditions, boosting efficiency up to 98% and reducing heat output. The UPS automatically reverts to full double-conversion when utility quality degrades.
Q: Does the GXT5-1000LVRT2UXLTAAN support SNMP monitoring?
A: Not out of the box. SNMP and web management require the optional Vertiv Liebert IntelliSlot RDU120 communications card (sold separately). USB and RS232/RS485 serial connections are available without any add-on card for local or direct-connect monitoring.
Q: Can the GXT5-1000LVRT2UXLTAAN be used in both rack and tower configurations?
A: Yes. The chassis converts between 2U rack-mount and freestanding tower orientation. The colored LCD uses gravity sensing to rotate its display based on physical orientation, so status reads correctly in both configurations.
Q: What outlets does the GXT5-1000LVRT2UXLTAAN provide, and can they be controlled individually?
A: The unit has six NEMA 5-15R outlets. Four are individually programmable — you can assign load-shedding sequences, delayed startup, or separate power cycling per outlet. Two outlets are non-programmable and provide continuous power.
Q: What safety certifications does the GXT5-1000LVRT2UXLTAAN carry?
A: The unit is listed to UL 1778 4th edition and CSA 22.2 No. 107.1 for UPS safety. It also holds ENERGY STAR 2.0 certification, and complies with RoHS2, REACH, and WEEE environmental directives.
The GXT5-1000LVRT2UXLTAAN is one of the cleaner TAA-compliant UPS options at the 1000W tier precisely because it doesn't de-rate — the unity power factor means you're actually getting 1000W of usable output, not the 600–700W you'd see from older 1000VA units designed around 0.6–0.7 PF loads. For a rack holding an NVR, a managed PoE switch, and a couple of edge devices, that headroom is real.
Technical Highlights:
- Zero Transfer Time: Double-conversion topology means there is no switchover gap when utility power drops — the inverter is already running the load. For recording servers mid-write or access control panels mid-transaction, that's the spec that prevents file corruption and door-state errors.
- 98% ECO / 95% On-Line Efficiency: At continuous 24/7 operation, the difference between 92% (older UPS efficiency) and 98% ECO mode adds up — roughly 60W less heat per 1000W load, which matters in small IT closets without dedicated CRAC.
- 4 Programmable Outlets: The individually programmable receptacles let you script a power-restore sequence — NVR first, then cameras, then access control — rather than letting everything rush the network simultaneously after a utility event.
Deployment Considerations:
- SNMP monitoring requires the IntelliSlot RDU120 add-on card — budget for it if this UPS needs to report into a centralized monitoring platform. USB and serial are available native but are point-to-point only.
- At 37 lbs and 15.7 inches deep, verify rack depth before ordering — shallow-depth network cabinets (under 18 inches) may not accommodate the unit without a rail extension kit.
This unit fits well in a small-to-medium physical security head-end room: a 16-camera NVR running 24/7, a PoE switch, and a firewall can typically fit within 600–800W — leaving useful reserve on the 1000W output while staying TAA-compliant for the government site manager who signs the procurement order.
