Vertiv 4114277 Concise Descriptor
Overview
The Vertiv 4114277 is a specialized cable connector designed to interface with Vertiv's GXT5 series Uninterruptible Power Supply (UPS) Extended Battery Cabinets (EBC). This component ensures a secure and reliable power connection between the UPS and its external battery modules, critical for maintaining uptime during power disturbances. Deploy this connector when expanding the battery runtime of your Vertiv GXT5 UPS system to match your specific operational demands.
Compatibility
This 4114277 connector is specifically engineered for use with the following Vertiv GXT5 UPS models and their corresponding Extended Battery Cabinets:
- GXT5-EBC36VRT2U: Compatible with GXT5-750IRT2UXLE and GXT5-1000IRT2UXLE UPS models.
- GXT5-EBC48VRT2U: Compatible with GXT5-1500IRT2UXLE and GXT5-2000IRT2UXLE UPS models.
- GXT5-EBC72VRT2U: Compatible with GXT5-3000IRT2UXLE UPS models.
- GXT5-EBC192VRT3U: Compatible with GXT5-5000IRT5UXLE, GXT5-6000IRT5UXLE, GXT5-8000IRT5UXLE, and GXT5-10KIRT5UXLE UPS models.
- GXT5-EBC384VRT6U: Compatible with GXT5-16KIRT9UXLE and GXT5-20KIRT9UXLE UPS models.
Verify your specific UPS and EBC model numbers against this list to ensure correct part selection.
Installation Notes
The Vertiv 4114277 connector facilitates the physical link between the UPS and the EBC. Ensure that power to both the UPS and the EBC is completely disconnected before attempting installation. The connector is designed for a secure fit; apply firm pressure to seat it properly. Refer to the specific GXT5 UPS and EBC installation manuals for detailed wiring and connection procedures. The weight of the component is approximately 1.00 lbs.
What's in the Box
- 1x Vertiv 4114277 EBC Cable Connector
