Geovision 84-FD320-D01U 3MP IR Dome IP Camera
Overview
The Geovision 84-FD320-D01U is a 3MP fixed dome camera with varifocal optics (2.7–9mm) and integrated IR illumination, built for indoor and semi-outdoor surveillance where flexible field-of-view customization saves on lens swaps and installation labor. The dome form factor is discreet and compact—it fits standard ceiling cutouts and pendant mounts, making retrofit work straightforward. The 3MP sensor delivers enough resolution for subject identification in access control, retail, facility monitoring, and corridor coverage scenarios. H.264 compression keeps storage consumption reasonable without sacrificing detail, and IR extends operation into complete darkness, eliminating the need for auxiliary lighting in storage areas, server rooms, and other low-ambient-light facilities. The varifocal lens means you adjust horizontal and vertical field of view during commissioning—no need to stock multiple fixed-lens variants or reconfigure cabling if coverage requirements shift before or after handoff.
Compatibility
The 84-FD320-D01U integrates with any surveillance infrastructure that accepts standard IPCAM cabling and ONVIF/IP protocols. It works with Geovision management platforms and third-party VMS systems (Milestone, Genetec, and other ONVIF-compatible control software) via standard IP video streams. PoE power delivery simplifies installation—no separate 12V supply or bulky wall transformer required. The camera supports DHCP and static IP assignment, event-triggered recording, and mixed-brand deployments in larger multi-vendor ecosystems.
Installation Notes
Mount to ceiling or pendant bracket using the compact dome footprint. Standard RJ-45 cabling delivers both video and power (PoE) from a compatible switch or injector. The varifocal lens requires focus and zoom adjustment during commissioning—plan 15–30 minutes per camera for optical tuning. IR performance improves in completely dark environments; mixed lighting (some ambient + IR) may cause reflection or glare from reflective surfaces near the camera.
What's in the Box
- 1x Geovision GV-FD320D dome camera (84-FD320-D01U)
- 1x varifocal lens (2.7–9mm, F2.7)
- Mounting hardware (bracket, screws)
