Panduit RGW-100-1Y Concise Descriptor

Overview

The Panduit RGW-100-1Y is a ground washer kit designed to ensure a secure and reliable electrical ground connection for 3/8" studs. This component is critical in electrical installations where proper grounding is essential for safety and system integrity, particularly in environments requiring robust grounding for sensitive equipment or compliance with electrical codes. It provides a consistent contact surface for grounding conductors.

Compatibility

This ground washer kit is specifically designed for use with 3/8" studs. It is compatible with Panduit's range of grounding and bonding products, as well as other electrical systems that utilize 3/8" stud sizes for grounding connections. Ensure your stud size matches precisely for optimal performance.

Installation Notes

For optimal performance and safety, the Panduit RGW-100-1Y should be installed on a clean, flat surface of the 3/8" stud. Torque specifications should be followed as per the electrical system's installation manual to ensure a secure connection without damaging the washer or the stud. Proper crimping of the ground lug onto the conductor is also critical for a complete grounding circuit.
