Panduit PN14-6F-C Ring Terminal
Overview
The Panduit PN14-6F-C is a #6 stud size, yellow, vinyl-insulated ring terminal designed for terminating 18 to 10 AWG stranded copper wire. It provides a secure and reliable electrical connection point for equipment with #6 stud-sized terminals, commonly found in control panels, power distribution units, and industrial machinery. This terminal ensures proper wire seating and prevents conductor strand separation during installation, critical for maintaining signal integrity and preventing shorts in sensitive electronic systems.
Compatibility
This terminal is designed for use with 18-10 AWG stranded copper wire and #6 stud-sized electrical connections. It is suitable for general-purpose electrical wiring applications where a secure ring termination is required. It is not specific to any particular surveillance or network equipment brand but is a standard electrical component for wiring infrastructure.
Installation Notes
For optimal performance and safety, use Panduit's recommended crimping tools, such as the CT-100, CT-1000, or CT-2500, to ensure a secure, vibration-resistant crimp. The recommended wire strip length is 1/4 inch (6.35mm). Ensure the terminal is fully seated on the stud and tightened to the manufacturer's specified torque for the connected equipment to prevent loosening or damage.
What's in the Box
- 100x Panduit PN14-6F-C Ring Terminals
