Middle Atlantic FWD-TSW-15 Forward Hook & Loop Tie Saddles — 15-Pack
Overview
The Middle Atlantic FWD-TSW-15 delivers 15 forward-style hook and loop tie saddles engineered for structured cable management inside AV and security racks. If you've ever fought a rats-nest of camera, power, and data cables inside a dense enclosure, these saddles are the surgical fix — they route and bundle conductors forward-facing so cables stay organized, accessible, and identifiable during future adds or service calls. The FWD-TSW-15 (often searched as FWD TSW 15) is a purpose-built Middle Atlantic accessory, and a natural companion to the broader Middle Atlantic rack and enclosure line.
Key Features
- Forward-Facing Saddle Design: The 'Forward' orientation routes cable bundles to the front plane of the rack rather than straight back — critical when you need repeated access to patch points or when cameras and NVR ports sit at the front of a shallow enclosure. Less cable stress, fewer accidental disconnects during service.
- 2.65-Inch Width: At 2.65 in (6.7 cm) across, each saddle handles a meaningful bundle diameter without forcing cables into a tight radius that could damage jacket or bend sensitive data runs. Wide enough for mixed camera, power, and network cable groupings common in NVR-based security installations.
- Hook and Loop Fastening: Reusable hook-and-loop strips mean you can open, re-route, and re-secure bundles during MACs (moves, adds, changes) without cutting and replacing zip ties. In an active installation where camera layouts evolve, this saves real time over the life of the system.
- Pantone 3015 Blue Color Coding: The defined blue (Pantone 3015) is not arbitrary — it allows color-coded cable pathway identification inside mixed-use enclosures. Pair blue saddles with one cable type (e.g., PoE camera runs) and a different-color accessory for another (e.g., control wiring) to make future troubleshooting faster.
- 15-Unit Pack Quantity: Sold in packs of 15, the FWD-TSW-15 gives you enough saddles to manage a fully loaded rack bay or distribute across multiple rack units without a second order. Each saddle ships individually usable — no assembly required.
- UPC-Coded for Procurement: The UPC marking on packaging streamlines PO processing and receiving for facilities and IT teams managing asset tracking through a WMS or procurement system. Minor detail, but it matters when you're receiving 20 line items at once on a large rack accessory order.
Integration & Compatibility
These saddles are designed for use with Middle Atlantic rack enclosures and are compatible with standard 19-inch rack infrastructure broadly. The forward-facing profile is particularly useful in reduced-depth enclosures where cable egress space behind the device plane is limited. Pair with Middle Atlantic vertical cable managers and patch panels to build a fully organized pathway from PoE switch to camera endpoints.
What's in the Box
- 15x Forward Hook & Loop Tie Saddles (Pantone 3015 Blue)
Frequently Asked Questions
Q: How many saddles are included in the FWD-TSW-15?
A: The FWD-TSW-15 includes 15 forward hook and loop tie saddles per pack.
Q: What color are the FWD-TSW-15 saddles?
A: They are blue, specifically Pantone 3015, which supports color-coded cable management schemes inside mixed-use rack enclosures.
Q: What does 'Forward' mean in the FWD-TSW-15 name?
A: 'Forward' refers to the saddle orientation — cables are routed toward the front plane of the rack rather than directed straight back. This is useful in shallow enclosures and anywhere front-of-rack access is required.
Q: Are the hook and loop ties reusable?
A: Yes. Hook and loop fastening is inherently reusable — you can open and re-secure bundles multiple times without replacing the saddle, unlike disposable zip ties.
Q: What is the width of each saddle?
A: Each saddle is 2.65 inches (6.7 cm) wide, accommodating multi-cable bundles of mixed camera, power, and data conductors typical in rack-mounted security installations.
The FWD-TSW-15 is one of those small-ticket items that pays for itself on the first service call. The 2.65-inch forward saddle width is well-chosen — wide enough to handle a mixed PoE camera and power bundle without forcing a tight bend radius that degrades Cat6 performance, yet narrow enough to stack multiple saddles per RU without crowding adjacent gear.
Technical Highlights:
- Pantone 3015 Blue: A defined color standard, not just 'blue' — means color-coding is repeatable across multiple orders and stays consistent when you're documenting cable pathways for handoff documentation.
- Forward Saddle Orientation: Front-plane cable routing is the correct choice for any enclosure under 24 inches deep where rear cable egress is restricted. It keeps cable bend radii compliant and eliminates the cable-crushing that happens when you try to force bundles into a tight rear pocket.
- 15-Unit Pack: Sizing a full 42U rack with saddles every 2U pulls approximately 21 saddles — two packs covers a standard full-height rack with a few spares for patch panels and horizontal managers.
Deployment Considerations:
- Plan saddle placement before pulling cable — saddles installed after the fact often end up in suboptimal positions that force cable back-routing to reach the anchor point.
- The Pantone 3015 blue is a specific color; if you're mixing these with saddles from other vendors or color families in the same enclosure, verify that your color scheme documentation references the Pantone number, not just 'blue,' to avoid future mismatches on expansion.
The FWD-TSW-15 is the right call for security integrators building out NVR enclosures in wiring closets or server rooms where cable density is high and MACs are expected — forward orientation keeps those bundles serviceable without a full re-pull every time a camera is added or relocated.
