Aiphone IXG-DM7-BOX Flush Mount Installation Box

Overview

The Aiphone IXG-DM7-BOX is a steel flush mount enclosure designed to house the IXG-DM7-HID door station in commercial and institutional access control installations. This box provides a recessed wall-mount solution that protects wiring and components while maintaining a clean, professional appearance on building entrances, office suites, and secured doorways. The 12-1/2" H × 6-1/8" W × 2-3/8" D (317mm × 156mm × 60mm) dimensions fit standard drywall cavity depths without excessive protrusion.

Key Features

• Steel construction: Corrosion-resistant material rated for indoor commercial environments. Provides mechanical protection for mounted equipment and internal wiring against incidental damage and tampering.
• Six conduit knockouts: Pre-drilled, knock-out style openings allow flexible conduit entry from multiple angles — typical layouts use 2–3 knockouts for power, data, and door control lines, leaving spares for future expansion or alternate routing without additional fabrication.
• Two integrated conduit provisions: The box ships with capacity for two conduit runs built into the design, matching standard installation patterns for access control (one for 24VDC power supply, one for Ethernet or door control cabling).
• Flush mount profile: Designed to sit behind drywall or panel surfaces, with the IXG-DM7-HID face plate mounted flush to the wall. Eliminates surface-mounted box aesthetics common in retrofits, preferred in corporate lobbies and institutional settings where finish appearance matters.
• Compact footprint: 2-3/8" depth fits within standard 2×4 stud cavity spacing without requiring notching or relocation of studs — speeds installation in new construction and major renovations.
• Standard form factor: Compatible with common electrical rough-in practices and drywall box sizing, reducing custom fabrication and lead time during integration phases.

Integration and Compatibility

The IXG-DM7-BOX is engineered as the primary mounting enclosure for the Aiphone IXG-DM7-HID video intercom door station. It serves as the structural backing and cable management point for all cabling runs — 24VDC power from the control unit, Ethernet for network connectivity, and door release/relay control lines. The box does not process video or audio; it acts purely as a protective and organizing vessel. Integrators install the box during rough-in phase (drywall framing), route conduit through knockouts, then mount the finished IXG-DM7-HID faceplate to the box exterior during trim-out. The box works with any Aiphone control system or third-party access control panel that supplies 24VDC power and supports Ethernet door station communication. No additional hardware or adapters are required beyond standard 3/4-inch or 1-inch conduit connectors (not included).

What's in the Box

The IXG-DM7-BOX ships as a single enclosure unit with no additional internal components, mounting hardware, or conduit connectors included. The box itself is the product.

Frequently Asked Questions

Q: Can I mount the IXG-DM7-BOX on a surface-mounted wall outside a stud cavity?

A: No. This box is designed for flush (recessed) installation within a 2×4 stud cavity. Surface mounting would expose the box and cables, defeating the aesthetic and protection purpose. For surface-mounted applications, you would need a different enclosure.

Q: How many conduit runs can I connect to the IXG-DM7-BOX?

A: The box features six pre-drilled conduit knockouts, allowing up to six separate 3/4-inch or 1-inch conduit connections. Most installations use 2–3 (power, Ethernet, door control), leaving spares for future cabling or alternate routing.

Q: What material is the IXG-DM7-BOX made from, and is it galvanized?

A: The box is constructed from steel. Confirm with the manufacturer whether it is galvanized or powder-coated for your specific environment — indoor commercial installations typically do not require additional corrosion treatment, but exterior or high-humidity areas may warrant specification verification.

Q: Is the IXG-DM7-BOX compatible with other intercom manufacturers' door stations?

A: No. This box is specifically designed for the Aiphone IXG-DM7-HID faceplate. Using it with other vendors' hardware risks improper fit, misaligned mounting holes, and cable management complications. Always verify enclosure compatibility with your door station model before ordering.

Q: Does the IXG-DM7-BOX include knockout removal tools or conduit connectors?

A: No. The box arrives ready to accept standard 3/4-inch and 1-inch knockout punches (standard electrician's tool) and external conduit connectors sourced separately. Budget these as job-site materials.

Q: Can this box be installed in damp or outdoor environments?

A: The IXG-DM7-BOX is rated for indoor commercial use. Outdoor or high-moisture environments require sealed, gasketed enclosures (typically NEMA 4X or IP67-rated). Do not use this box outdoors or in wet locations without additional weatherproofing, which would compromise its design integrity.

Ted Perry

The IXG-DM7-BOX is a straightforward but critical component of any flush-mount Aiphone IXG-DM7-HID installation. I've specified this box on dozens of corporate and institutional access control jobs, and the 12-1/2" × 6-1/8" × 2-3/8" steel frame is purpose-built to handle the rough-in-to-trim-out workflow without surprises. The six conduit knockouts give installers real flexibility on cabling paths — standard practice is to use three (power, Ethernet, door control), but having three spares prevents the "what if we need to relocate the next junction?" problem mid-project.

Technical Highlights:

• Steel construction with six knockout ports: Provides mechanical stiffness and multiple entry paths for 3/4-inch or 1-inch conduit, eliminating the need to drill custom holes or stack adapters if your site conditions require non-standard conduit routing.
• 2-3/8" depth matches standard 2×4 stud cavities: This dimension is non-negotiable for new construction and major renovations. A box that protrudes more than 2.5" either doesn't fit the cavity or forces you to relocate studs — either way, your timeline takes a hit. This one fits without negotiation.
• Flush-mount profile: Sits entirely behind drywall. The faceplate (mounted to the box) sits flush to the finished wall. If you've ever walked into a corporate lobby and seen a door intercom that looks like it belongs there rather than bolted on top, that's a flush-mount box doing its job. Appearances matter on main entrances and boardrooms.

Deployment Considerations:

• Install this box during rough-in, before drywall. Route your conduit during framing. Waiting until after drywall is up means cutting access holes, which defeats the cost and aesthetic advantage of a recessed enclosure.
• The box itself includes no conduit connectors or knockout-removal tools — those are standard electrician's stock items, but don't assume the GC has them on site. Verify during material takeoff so you're not waiting on a hardware store run during trim-out.
• This is an indoor commercial enclosure. If your door station faces a covered porch or any weather-exposed location, this box is not rated for moisture. You'll need a weatherproof, gasketed alternative — verify the environment during design, not after the box arrives on site.

Use the IXG-DM7-BOX on corporate office suites, institutional main entrances, and any new or renovation project where the IXG-DM7-HID door station needs to be recessed into the wall. Skip it if you're retrofitting onto an existing surface-mounted door frame or if the application requires outdoor/wet-location protection.
