Panduit FPONE1 Fiber Enclosure

Overview

The Panduit FPONE1 is a compact, light gray enclosure designed for terminating and managing passive optical fiber connections. Constructed from durable PC+ABS material, it provides an IP55 rating, offering protection against dust ingress and low-pressure water jets. This makes the FPONE1 suitable for deployment in environments where environmental factors are a concern, such as telecommunications rooms or industrial settings. Its design facilitates organized fiber management, preventing damage and ensuring signal integrity for passive optical networks. The FPONE1 model specifically supports up to 12 SC adapters and one splitter module, enabling flexible network configurations.

Compatibility

This enclosure is designed to accommodate standard SC fiber optic adapters and passive splitter modules (N x 2, N x 4, and N x 8 configurations). It is compatible with a wide range of passive optical network (PON) deployments where fiber termination and distribution are required. The specific dimensions (233 x 200 x 63 mm) should be verified against available rack or wall space for integration into existing infrastructure.

Installation Notes

The enclosure features a light gray finish and is rated IP55, indicating it should be installed in locations protected from direct high-pressure water streams or submersion. Ensure mounting surfaces are stable to support the enclosure and its terminated fiber connections. Proper cable management within and outside the enclosure is recommended to maintain bend radius requirements and prevent signal loss.
