Panduit FF 800X45RU1200 TC SGL HFD SRD L-R SP CSTR PK 1 BLK - XG84522BS008V

Panduit XG84522BS008V Single-Sided High-Density Frame

Overview

The Panduit XG84522BS008V is a single-sided, high-density patch panel frame designed for structured cabling systems in data centers and enterprise networks. This frame supports up to 45 RU of equipment, providing a compact and organized solution for managing a large number of network connections within a limited rack space. Its robust construction ensures stability for network infrastructure, and the black finish offers a professional aesthetic. The XG84522BS008V is engineered to streamline cable management, reducing clutter and improving airflow for optimal equipment performance.

Compatibility

This frame is compatible with Panduit's range of high-density fiber optic and copper patch panels, including the QuickNet™ series. It is designed to fit standard 19-inch racks and cabinets, accommodating a variety of network equipment. Specific compatibility extends to Panduit's HD (High Density) modules and accessories, ensuring a cohesive and integrated cabling solution.

Installation Notes

Installation requires mounting to standard 19-inch rack rails. Ensure rack posts are plumb and level. The frame is designed for single-sided access, meaning all patching and management occur from the front. Proper cable management accessories, such as cable managers and ties, are recommended to maintain organization and airflow within the rack. Torque specifications for rack mounting hardware should be followed as per standard data center practices.

What's in the Box

• 1x Panduit XG84522BS008V Frame
• 1x Mounting Hardware Kit
