Panduit DNF14250FIBX-2K Female Disconnect Terminal

Overview

The Panduit DNF14250FIBX-2K is a female disconnect terminal designed for terminating 16-14 AWG wire. It features a standard .250 inch (6.35mm) tab width, ensuring compatibility with common disconnect switches and mating male terminals. This terminal is engineered for reliable electrical connections in control panels, power distribution systems, and industrial automation applications where secure and efficient wire termination is critical. Its construction provides a robust connection point for power and signal wiring, reducing the risk of intermittent connections or component failure.

Compatibility

This terminal is designed to mate with standard .250 inch (6.35mm) male disconnect tabs. It is suitable for use with wire gauges ranging from 16 AWG to 14 AWG. Applications include terminating wires for relays, solenoids, motor controls, and other electrical devices requiring a quick-connect interface. It is compatible with Panduit's extensive line of crimping tools for secure installation.

Installation Notes

For optimal performance and connection integrity, use Panduit's recommended crimping tools, such as the CT-100, CT-1550, CT-2500, or CT-3000 series, with appropriate die sets for 16-14 AWG wire. Ensure the wire is stripped to the correct length (typically 1/4 inch or 6.35mm) before insertion into the terminal barrel. Crimp the barrel securely onto the wire insulation and conductor to prevent pull-out and ensure low resistance. The terminal is designed for use in electrical systems operating within standard temperature and voltage ranges for its wire gauge class.
