Panduit CFPL2SY Mini-Com 2-Port Stainless Steel Faceplate
The Panduit CFPL2SY delivers ruggedized termination for high-traffic commercial environments where polymer faceplates fail. This single-gang stainless steel faceplate accepts two Mini-Com modules in any configuration—copper, fiber, A/V, or hybrid—and mounts to standard NEMA electrical boxes without adapters. Built-in label pocket simplifies documentation in multi-tenant buildings, data centers, and industrial facilities where movable adds and changes demand fast field identification. The polished metallic finish resists impact, corrosion, and UV degradation in warehouse loading docks, manufacturing floors, and outdoor-rated enclosures.
Key Features
- Stainless steel construction withstands impact and corrosion in industrial and high-traffic areas
- Single-gang NEMA form factor mounts directly to standard electrical boxes
- Two-port capacity supports any Mini-Com module combination (copper, fiber, A/V, or coax)
- Integrated label pocket enables fast port identification without adhesive labels
- Polished metallic finish maintains appearance in public-facing installations
- RoHS compliant for government and enterprise procurement requirements
The CFPL2SY measures 4.51" H × 2.76" W (114.6 × 70.1mm)—matching single-gang electrical box dimensions across North America and most international markets. Stainless steel construction provides three advantages over thermoplastic alternatives: first, superior impact resistance when carts, equipment, or foot traffic strike the wall; second, corrosion resistance in humid environments, food-service facilities, or coastal installations where salt air degrades painted metal; third, fire-performance characteristics that meet stricter building codes in hospitals, schools, and government facilities. The faceplate screws directly to 1-gang mud rings or device boxes without requiring a separate mounting bracket or adapter plate. Port spacing accommodates standard Mini-Com latching mechanisms without interference, and the recessed label pocket accepts adhesive or write-on inserts up to 1.5" wide.
Integrators deploy the CFPL2SY in scenarios where aesthetics, durability, and flexibility converge: warehouse offices needing both data and PoE camera drops at a single wall location; hospitality guest rooms requiring copper Ethernet plus coax TV in a cleanable metallic finish; manufacturing control rooms where fiber uplinks and copper workstation ports terminate in the same faceplate; and retail back-offices where frequent re-cabling demands tool-free module swaps. The Sub-Brand designation Pan-Net indicates compatibility with Panduit's full ecosystem of Mini-Com jacks, fiber adapters, A/V inserts, and blank modules, letting you populate ports as needed without committing to a fixed configuration. In multi-floor tenant build-outs, maintenance teams use the label pocket to print floor/room/circuit identifiers, reducing troubleshooting time when a user reports a dead port.
Stainless steel also delivers tangible value in outdoor-rated enclosures and wash-down environments: unlike painted steel that rusts when the coating chips, or UV-sensitive plastic that becomes brittle after two years of sunlight exposure, the CFPL2SY maintains structural integrity and latch retention across temperature swings from -20°F to +140°F. Carton quantity of 10 supports mid-size rollouts without overstocking, and RoHS compliance ensures the product meets California, EU, and federal e-waste regulations for bid specifications requiring documented material declarations.
