Vertiv EXM 208 20K Wmbc Tmag 3 Breaker W/ Kirk KEY - WMBC208-EXM20K3BTK

Vertiv WMBC208-EXM20K3BTK Power Distribution Module

Overview

The Vertiv WMBC208-EXM20K3BTK is a 20kW, 208V power distribution module designed for rack-based IT infrastructure. It integrates three circuit breakers, including a Kirk Key interlock mechanism, to ensure safe and sequential power activation in critical environments. This module is essential for managing power distribution in data centers, server rooms, and other high-density computing deployments where reliable power is paramount.

Compatibility

This module is designed for use with Vertiv rack systems and compatible power distribution units (PDUs). It is specifically engineered to integrate with 208V power sources and is intended for use within Vertiv's modular infrastructure solutions. Consult your Vertiv system documentation for exact compatibility with specific rack chassis and PDU models.

Installation Notes

Installation requires qualified personnel familiar with high-voltage electrical systems. The Kirk Key interlock system mandates a specific sequence for power activation and deactivation, preventing accidental power loss to critical equipment. Ensure proper torque specifications are met for all electrical connections to prevent overheating and ensure system integrity. The module requires a 208V, 3-phase power input and provides three distinct breaker outputs.

What's in the Box

• 1x Vertiv WMBC208-EXM20K3BTK Power Distribution Module
• 1x Kirk Key Interlock System (integrated)
• 3x Circuit Breakers (integrated)
• Mounting hardware
