Vertiv GL48UEX-60160W-MM-PL 48U 600mm x 1600mm White Server Rack Cabinet

Overview

The Vertiv GL48UEX-60160W-MM-PL is a 48U, 600mm-wide by 1600mm-deep server rack cabinet in white — a standard-footprint enclosure from the Vertiv server rack and enclosure lineup suited for data center rows, network operations rooms, and server closets where the full 48U of mounting space and a 1600mm depth accommodate deep compute and networking hardware. The 600mm width fits the industry-standard EIA 19-inch rail pattern, and the 1600mm depth provides clearance for high-density server rack cabinets with front and rear cable runs without forcing bend-radius compromises on patch cords or power whips. The white finish suits environments where color coding separates network, compute, and power rows, or where facility standards call for a lighter enclosure color in raised-floor or co-location deployments.

Key Features

• 48U Mounting Space: Forty-eight rack units of usable vertical space accommodates a full stack — top-of-rack switch, patch panels, 1U/2U servers, and PDUs — without requiring a second cabinet in most mid-density builds. That eliminates inter-cabinet cabling runs and simplifies inventory.
• 600mm Cabinet Width: Matches the EIA 310-D 19-inch rail standard, so standard server, networking, and AV equipment mounts without adapter brackets. The 600mm external width also fits the typical raised-floor tile grid and hot-aisle/cold-aisle row spacing used in most enterprise data centers.
• 1600mm Cabinet Depth: The 1600mm internal depth accommodates today's longest 1U and 2U servers — many of which run 900–1000mm front-to-rear — while still leaving room for structured rear cabling, vertical cable managers, and rear-mounted PDUs. Shallower 1000mm or 1200mm cabinets force tray extensions or door removal on deep chassis; this cabinet avoids that compromise.
• White Finish: The white powder-coat finish is specified for deployments where cabinet color is a facility or operational requirement — common in medical, broadcast, and co-location environments that use color to distinguish equipment zones or match room aesthetics.

Integration and Compatibility

At 600mm wide and 1600mm deep, the GL48UEX-60160W-MM-PL accepts standard 19-inch EIA rack-mount equipment across all major server, networking, KVM, and power distribution categories. The 48U height makes it compatible with standard overhead cable tray routing and typical raised-floor ceiling clearances. For deployments pairing this cabinet with network switches, patch panels, and structured cabling overhead pathways, the 1600mm depth ensures rear cable egress does not conflict with rear door closure. For power distribution within the cabinet, consult Vertiv's PDU and UPS line to match outlet count and form factor to your planned rail layout. For procurement on larger rollouts, infrastructure planning resources covering PoE, cabling, and rack density are available to help size the full deployment.

Frequently Asked Questions

Q: What is the rack unit capacity of the GL48UEX-60160W-MM-PL?

A: The GL48UEX-60160W-MM-PL provides 48U of usable rack space, accommodating a full complement of servers, networking gear, patch panels, and power distribution units in a single enclosure.

Q: What are the external dimensions of this cabinet?

A: The cabinet is 600mm wide and 1600mm deep. Height corresponds to a standard 48U enclosure (approximately 2200mm or 86.6 inches tall for a 48U frame, though exact external height should be confirmed against the Vertiv product datasheet). Width of 600mm fits the standard EIA 19-inch rail pattern.

Q: Why is the 1600mm depth significant for server deployments?

A: Modern 1U and 2U servers frequently measure 900–1000mm front-to-rear. A 1600mm-deep cabinet provides adequate clearance for the chassis, rear cable dressing, and PDU mounting without requiring door removal or cable tray extensions — which are common workarounds in shallower 1000mm or 1200mm cabinets.

Q: Is the white finish a standard option or a special order?

A: The white finish is a factory-specified option encoded in the GL48UEX-60160W-MM-PL part number (the 'W' suffix). It is not a field-applied coating — the cabinet ships in white from the factory, making it a valid standard-procurement option for facilities with color requirements.

Q: Does this cabinet ship on a pallet?

A: Yes. The 'PL' suffix in the part number GL48UEX-60160W-MM-PL indicates pallet delivery, which is standard for full-size 48U enclosures of this depth and weight class to prevent shipping damage.

Ted Perry

The GL48UEX-60160W-MM-PL is the right call when you need a full 48U of vertical space in a 600x1600mm footprint and your facility spec or row-coding scheme requires white. The 1600mm depth is the dimension I pay attention to here — it is not a vanity spec. If you are racking current-generation compute hardware, that extra depth versus a 1200mm cabinet is the difference between a clean rear cable run and a door that won't close without adapter trays.

Technical Highlights:

• 48U Vertical Capacity: Eliminates the need for a second enclosure in most mid-density single-row deployments — one cabinet handles top-of-rack switching, patch density, compute, and PDU in a single managed unit.
• 1600mm Depth: Sized for deep-chassis servers and dual-port rear cable egress simultaneously — a practical requirement when rear PDUs and structured cabling both need to exit without competing for the same 200mm of clearance.
• White Factory Finish: Encoded as a factory option in the part number suffix, not a field modification — important for procurement teams who need color consistency across a multi-cabinet row without field painting or vinyl wraps.

Deployment Considerations:

• Confirm your facility's floor tile grid and aisle width before specifying 600mm-wide cabinets in a high-density row — some older raised-floor grids were laid for 800mm-wide footprints and may require repositioning to align with tile cutouts and underfloor airflow patterns.
• The 'PL' pallet suffix confirms freight delivery rather than parcel — coordinate dock access and a pallet jack or forklift for receiving before the unit ships, particularly in upper-floor data center buildouts where elevator dimensions are a constraint.

This cabinet is the right fit for a co-location cage, medical imaging equipment room, or broadcast infrastructure rack where white is a hard facility requirement and the full 1600mm depth is needed to avoid chassis-clearance compromises on deep compute hardware.
