Bosch NDA-U-DWMT Dual Pendant Wall Mount

Overview

The Bosch NDA-U-DWMT is a robust dual pendant wall mount designed for secure and versatile camera installations in challenging environments. It provides a stable platform for mounting two cameras or a camera and an illuminator, supporting a maximum load of 8 kg (17.64 lb). This mount is engineered for resilience, featuring NEMA TS2 vibration resistance, IP66 water and dust ingress protection, and IK10 impact resistance, making it suitable for outdoor applications exposed to harsh weather and potential vandalism. The RAL 9003 signal white finish ensures it blends with most commercial exteriors.

Compatibility

This mount utilizes universal hardware, making it compatible with a wide range of Bosch surveillance cameras and accessories that use standard mounting interfaces. It is particularly well-suited for pendant-mounted cameras requiring a secure wall attachment point. For specific camera model compatibility, consult the Bosch camera datasheets or the accessory compatibility matrix.

Installation Notes

The mount is constructed from durable aluminum and rubber, weighing 12.17 lb (5521 g). Its dimensions are 7.28 in. x 14.37 in. x 9.62 in. (185 mm x 365.13 mm x 244.46 mm). The NEMA TS2 rating indicates it can withstand moderate levels of shock and vibration typically found in traffic or industrial settings. The IP66 rating ensures protection against high-pressure water jets and dust ingress, while IK10 provides resistance against 20 joules of impact energy, equivalent to a 5 kg mass dropped from 40 cm.

What's in the Box

• 1x NDA-U-DWMT Dual Pendant Wall Mount
• 1x Mounting Hardware Kit
