Zebra DS9308-SR Black USB Kit: DS9308-SR00004ZZWW Scanner CBA-U21-S07ZBR - DS930 - view 6
Zebra DS9308-SR Black USB Kit: DS9308-SR00004ZZWW Scanner CBA-U21-S07ZBR - DS930 - view 6
Zebra DS9308-SR Scanner - DS9308-SR4U2100AZW
Product images are provided for reference and may not represent the exact model, configuration, or included components.

No Bots, Just Experts

Questions about this product? Free pre-sales support from a senior specialist — product questions, compatibility checks, BOM quotes, price confirmation — typically answered within one business day. Need camera placement or system design work? Engineering time is $175 per hour (qty 1 = 1 hour). Hardware buyers get up to one hour ($175) credited back on their order.

Get Free Pre-Sales Support Buy Design Hours ($175/hr)
Description

Zebra DS9308-SR4U2100AZW Concise Descriptor

Overview

The Zebra DS9308-SR4U2100AZW is a compact presentation scanner designed for high-volume retail environments where counter space is limited and checkout speed is critical. Its ability to scan challenging 1D and 2D barcodes rapidly, coupled with intelligent illumination, ensures efficient customer transactions. The scanner's durable construction withstands everyday drops and spills, maintaining operational uptime in demanding point-of-sale scenarios. This specific kit includes the DS9308-SR scanner, a shielded USB cable (CBA-U21-S07ZBR), and a protective shroud, providing a complete solution for immediate deployment.

Compatibility

This scanner is designed to integrate with point-of-sale systems via USB. It is compatible with standard POS software that accepts keyboard wedge or USB serial emulation input. The included shielded USB cable ensures a reliable connection. It is suitable for use with most modern POS terminals and cash registers that provide a USB port.

Installation Notes

The DS9308-SR4U2100AZW utilizes standard USB connectivity, requiring no special drivers for most operating systems. Plug-and-play functionality allows for immediate use. The intelligent adaptive illumination system automatically adjusts LED brightness, minimizing eye annoyance and power consumption when not actively scanning. The scanner's near-zero footprint design allows it to be placed unobtrusively on any counter.

What's in the Box

  • 1x DS9308-SR Scanner (DS9308-SR00004ZZWW)
  • 1x Shielded USB Cable (CBA-U21-S07ZBR)
  • 1x Scanner Shroud
Expert Analysis
Specifications
Dimensions: 5.7 in. H x 3.4 in. W x 3.3 in. D
Weight: 11.2 oz. / 318.0 g
Input Voltage Range: 4.5 to 5.5 VDC
Operating Current: 335mA (Presentation), 350mA (Trigger)
Standby Current: 135mA (Presentation), 75mA (Trigger)
Color: Alpine White, Midnight Black
Supported Host Interfaces: USB, RS232, Keyboard Wedge, TGCS (IBM) 46xx over RS485
Symbol Decode Capability: 1D, 2D, OCR, MICR, Digimarc
Swipe Speed: Up to 120 in./305 cm. per second
Imager Field Of View: 52° H x 33° V nominal
Image Sensor Resolution: 1280 x 800 pixels
Skew Tolerance: +/-60°
Pitch Tolerance: +/-60°
Roll Tolerance: 360°
Operating Temperature: 32.0° F to 122.0° F / 0.0° C to 50.0° C
Storage Temperature: -40.0° F to 158.0° F / -40.0° C to 70.0° C
Humidity: 5% to 95% RH, non-condensing
Drop Specification: Designed to withstand 5.0 ft. / 1.5 m drops to concrete
Tumble Specification: Designed to withstand 1,000 tumbles of 1.5 ft. /0.5 m
Environmental Sealing: IP52
Electrostatic Discharge Immunity: +/-15 KV Air, +/-8 KV indirect
Ambient Light Immunity: 0 to 107,700 Lux
Warranty: 3 years
