APC by Schneider Electric Door Post 900 - 1200MM (36 - 48IN) Aisle Width - ACDC2404

APC by Schneider Electric ACDC2404 Door Post, 900–1200mm Aisle Width

Overview

The APC by Schneider Electric ACDC2404 is a door post designed for hot-aisle or cold-aisle containment systems in structured data center and server room deployments. It accommodates aisle widths from 900mm to 1200mm (36 to 48 inches), making it suitable for a range of standard row configurations without requiring custom fabrication. The post ships in black and integrates with APC by Schneider Electric containment infrastructure to close off open aisle ends — a step that meaningfully improves cooling efficiency by preventing bypass airflow between hot and cold zones.

Compatibility

The ACDC2404 is purpose-built for APC aisle containment systems. Its 900–1200mm width range covers the most common data center row spacings used with APC NetShelter and comparable rack families. The post measures 400mm wide × 315mm tall with a maximum depth reach of 2,480mm, so confirm your row depth before ordering — this is a structural component and incorrect depth sizing will prevent a clean seal. As part of the broader data center physical infrastructure category, it pairs with compatible aisle doors, roof panels, and end-of-row assemblies.

Installation Notes

The unit ships at a packaged weight of 20.6kg (package dimensions: 2,306mm × 268mm × 192mm), so plan for two-person handling during installation. The product carries RoHS and REACH compliance certifications — relevant for enterprise and government deployments with materials restriction requirements. No electrical connections are involved; installation is mechanical only. Consult your aisle containment layout plan and verify row width measurements before mounting. Review data center cooling planning resources to confirm containment strategy before specifying end-of-row door hardware.

Frequently Asked Questions

Q: What aisle widths does the ACDC2404 accommodate?

A: The ACDC2404 is designed for aisle widths from 900mm to 1200mm (36 to 48 inches).

Q: What are the physical dimensions of the ACDC2404?

A: The door post measures 400mm wide, 315mm tall, and reaches a maximum depth of 2,480mm. Packaged dimensions are 2,306mm × 268mm × 192mm at a weight of 20.6kg.

Q: Is the ACDC2404 RoHS compliant?

A: Yes. The ACDC2404 carries both RoHS and REACH compliance certifications.

Q: Does the ACDC2404 require electrical installation?

A: No. The ACDC2404 is a mechanical structural component only — no electrical connections are required.

Q: What color is the ACDC2404?

A: The ACDC2404 is finished in black.

James Everett

The ACDC2404 comes up most often in aisle containment retrofit projects where row widths have already been locked in during initial build-out. The 900–1200mm adjustment range is the practical detail — it covers the gap between tightly spaced and generously spaced rows without requiring a different SKU for each configuration. That said, the 2,480mm maximum depth is a hard ceiling: if your row runs deeper, this post won't seal the end cleanly, and a containment gap defeats the thermal separation you're trying to achieve.

Technical Highlights:

• 900–1200mm Width Range: Spans common aisle spacings in a single SKU — reduces the number of containment part numbers to stock and simplifies procurement for multi-row deployments.
• RoHS and REACH Certified: Both certifications are verified for the ACDC2404, which matters for government, healthcare, and EU-regulated facilities with materials compliance requirements.
• 20.6kg Packaged Weight: At this weight and with a package length over 2.3 meters, two-person installation is not optional — factor that into your labor estimate before scheduling the containment work.

Deployment Considerations:

• Verify your row depth against the 2,480mm maximum before ordering — depth mismatch on a structural containment post means it cannot be field-modified and will need to be exchanged.
• This is a mechanical-only component; no power, cabling, or network drops are involved, so installation can proceed independently of electrical scheduling.

Best fit for data center managers retrofitting aisle containment on existing NetShelter or comparable APC rack rows where row width falls in the 900–1200mm range and a code-compliant, materials-certified post is required.
