Bosch MBV-BPLU-DIP DIVAR IP License Plus Base for DIP AIO 6000-7000
Overview
The Bosch MBV-BPLU-DIP is the base software license that activates the DIVAR IP all-in-one 6000 and 7000 series appliances at their full 256-channel capacity — purpose-built for enterprise security deployments where a single, rack-mounted recording platform needs to handle a large camera count without a separate server build. Integrated on a 3U chassis with a hot-swap redundant power supply, dual Gigabit LAN, and 192 TB gross storage across 16 hot-swap 3.5-inch SATA trays in RAID-5, this platform is the kind of appliance a system integrator can rack, cable, and hand off to an IT team without extensive custom configuration. For buyers evaluating the broader Bosch Security Systems catalog, this license is the activation key that separates a powered-on box from a fully commissioned network video recorder.
Key Features
- 256-Channel Capacity: At maximum license, the MBV-BPLU-DIP supports 256 simultaneous camera streams — enough headroom for a mid-size campus, multi-building corporate site, or large retail chain without daisy-chaining appliances and multiplying management overhead.
- 192 TB Gross Storage in RAID-5: Sixteen 3.5-inch SATA trays provide 192 TB raw across a RAID-5 array. RAID-5 means you lose one drive's worth of capacity to parity but gain fault tolerance — a single drive failure does not take the system offline. On a 256-camera deployment running compressed video, that storage footprint supports meaningful retention windows. Plan your usable capacity after RAID overhead before committing to a retention SLA.
- Hot-Swap Redundant Power Supplies: Dual hot-swap PSUs rated for 100–240 V / 50–60 Hz input and a peak draw of 449.9 W (1,535.4 BTU/h) mean a power supply failure does not require a maintenance window. For 24/7 security infrastructure, this is a non-negotiable spec — and one worth confirming your PDU and UPS can handle at full load before rack installation.
- Intel Xeon Quad-Core Processor + 8 GB DDR3-1666 ECC UNB: The Xeon platform with ECC unbuffered memory provides hardware-level memory error correction — reducing the risk of silent data corruption on a system that records continuously. This is the right CPU tier for an appliance managing hundreds of concurrent streams and simultaneous playback requests.
- Dual Gigabit LAN: Two independent Gigabit interfaces allow network segmentation — camera network on one port, management/VMS client network on the other — without buying a separate NIC. On a 256-camera site with high-bitrate streams, keeping recording traffic isolated from playback and admin traffic is a practical necessity, not just a best practice.
- Microsoft Windows Storage Server 2016 OS: Running on a Windows Server platform means it integrates into existing Active Directory environments, supports standard Windows-based backup agents, and is familiar to IT teams who maintain enterprise infrastructure. It also means standard Windows patching applies — factor that into your change management process.
- 3U Rack Form Factor (132 × 437 × 648 mm, 32.7 kg): At 3U and 32.7 kg, this is a heavy appliance that warrants rail kit planning and two-person installation. Confirm your rack has adequate depth (648 mm) and that your rack rails are rated for the weight before shipping to site.
Integration and Compatibility
The MBV-BPLU-DIP is designed specifically for the DIVAR IP AIO 6000 and 7000 series hardware platforms. The License Plus designation activates the full channel count — buyers should verify whether their specific AIO unit ships with a base channel allotment that requires this license to unlock the 256-channel ceiling, or whether this license is the base activation for the appliance. Integrate this platform into your existing video management software environment by confirming Bosch BVMS or compatible ONVIF-based VMS support prior to deployment. For sites requiring extended storage or additional redundancy beyond what this appliance provides natively, evaluate pairing with a dedicated network-attached storage solution to extend retention without replacing the recorder. Review your PoE switch infrastructure to confirm you have adequate bandwidth and port density for the full 256-camera build-out before commissioning.
Frequently Asked Questions
Q: What is the maximum number of camera channels supported by the MBV-BPLU-DIP?
A: The MBV-BPLU-DIP supports up to 256 camera channels on compatible DIVAR IP AIO 6000 and 7000 series appliances.
Q: What is the gross storage capacity and RAID configuration on this appliance?
A: The appliance provides 192 TB gross storage across 16 hot-swap 3.5-inch SATA drive trays configured in RAID-5. RAID-5 tolerates a single drive failure without data loss or system downtime.
Q: What is the warranty on the MBV-BPLU-DIP?
A: The MBV-BPLU-DIP carries a 3-year manufacturer warranty.
Q: Does this appliance have redundant power supplies?
A: Yes. The platform includes hot-swap redundant power supplies supporting 100–240 V / 50–60 Hz input with a maximum power draw of 449.9 W, so a single PSU failure does not take the system offline.
Q: What operating system does the DIVAR IP AIO run?
A: The appliance runs Microsoft Windows Storage Server 2016, which supports Active Directory integration and standard Windows-based management and patching workflows.
Q: What are the physical dimensions and weight of this appliance?
A: The unit measures 132 × 437 × 648 mm (H × W × D) in a 3U rack form factor and weighs 32.7 kg. Two-person installation and rail kit planning are strongly recommended.
The MBV-BPLU-DIP is the license that makes the DIVAR IP AIO a real enterprise recorder — without it, the hardware is a chassis waiting for activation. At 256 channels on a single 3U appliance with 192 TB RAID-5 and hot-swap everything, this is a platform I'd spec for a 150–250 camera deployment where the customer wants a finished appliance instead of a build-it-yourself server. The Intel Xeon with ECC memory is the right foundation for continuous 24/7 recording at that channel count.
Technical Highlights:
- 192 TB RAID-5 Storage: Sixteen hot-swap 3.5-inch SATA trays give you real fault tolerance — one drive dies, recording continues. Calculate usable capacity after parity overhead (roughly 15/16 of gross) against your target retention window before finalizing the order.
- Hot-Swap Redundant PSUs at 449.9 W Peak: Both power supplies can be swapped under load. At 449.9 W max draw, make sure your rack PDU circuit is sized for it — a 20A circuit at 120V gives you roughly 1,920W headroom, so this box alone isn't the problem, but factor it into total rack load calculations.
- Dual Gigabit LAN: Two independent NICs let you put camera ingestion traffic on one interface and VMS client/management traffic on the other. On a 256-camera site, that separation matters — saturating one interface with recording traffic while clients are pulling simultaneous playback is a real problem this architecture avoids.
Deployment Considerations:
- At 32.7 kg and 648 mm deep, verify rack rail compatibility and plan for two-person installation — this is not a one-person lift and a short rack won't accommodate the depth.
- Windows Storage Server 2016 means standard Microsoft patch cadence applies. Budget for a maintenance window process; an unpatched recording server in a security environment is a liability, but an unplanned reboot during an incident is worse.
Best fit: a single-site enterprise deployment — corporate campus, hospital, or large government facility — where the customer needs 150–256 cameras on one managed appliance with IT-familiar OS and genuine storage redundancy, and where a custom-built server is not an option the team wants to support long-term.
