Digi International 76000697 Serial Adapter DTE DB-9
Overview
The Digi International 76000697 is a serial adapter designed to interface DTE (Data Terminal Equipment) devices with DB-9 serial ports. This adapter is crucial for integrating older industrial equipment, diagnostic tools, or legacy network gear that relies on serial communication into a modern IP-based infrastructure. Its primary function is to ensure reliable data transmission between serial devices and systems that may not have native serial ports, such as modern computers or network switches. The 76000697 model specifically provides a DTE interface, meaning it presents itself as a terminal device to the connected peripheral.
Compatibility
This adapter is designed for broad compatibility with any DTE device requiring a DB-9 serial connection. It is suitable for use with a wide range of industrial automation equipment, point-of-sale systems, network management consoles, and other legacy hardware. It functions as a passive adapter, so compatibility is determined by the serial port signaling standards (RS-232) of the connected devices rather than specific model numbers. Ensure your connected equipment is configured for DTE operation.
Installation Notes
The Digi International 76000697 is a passive adapter requiring no external power or configuration. Simply connect the DB-9 male connector to the DTE device's serial port and the DB-9 female connector to the cable leading to the DCE (Data Communications Equipment) or the target system. Its compact size and lightweight design (0.25 lbs) simplify installation in tight spaces. The dimensions are 9.0 x 7.0 x 2.0 inches, providing ample room for cable connections without excessive bulk.
What's in the Box
- 1x Digi International 76000697 Serial Adapter DTE DB-9
