Vertiv DC#14447 - Vertical Cable BAR KIT Includes 4W VCB (qty. 1) 25.5H X 4W HCB - CPQ-1041713-02

Vertiv CPQ-1041713-02 Vertical Cable Bar Kit

Overview

The CPQ-1041713-02 is a cable management kit from Vertiv's DC#14447 configuration, designed for structured vertical and horizontal cable routing inside compatible Vertiv enclosures. The kit pairs a 4W Vertical Cable Bar (VCB) with a 25.5H x 4W Horizontal Cable Bar (HCB), giving installers a matched set to organize and separate power and data cabling within a single rack unit — reducing cable strain, improving airflow lanes, and simplifying future moves, adds, and changes without pulling the entire bundle.

Compatibility

This kit is designed for use with Vertiv enclosures and rack systems that accept standard 4W cable management accessories. Verify bay width and mounting rail spacing against your specific Vertiv cabinet configuration before ordering — the 4W VCB footprint and the 25.5H HCB height dimension are the critical fit parameters. Consult the Vertiv Vertiv accessories catalog or your enclosure documentation to confirm compatibility with your cabinet series prior to installation. If you are also specifying rack cable management accessories for a larger deployment, confirm that the HCB height aligns with your vertical U-space allocation.

Installation Notes

Mount the VCB vertically along the rack side channel and the HCB horizontally at the designated height position within the enclosure. Ensure all cable ties or Velcro straps used to dress cables through the bars do not create bend radii below the minimum specified for the cable type — particularly relevant for fiber runs. Both components should be secured before populating the rack with active equipment to allow unobstructed cable dressing from the bottom up.
