Panduit CU COMPRESSION LUG 1 HOLE 250 K - LCAN250-38-X
Product images are provided for reference and may not represent the exact model, configuration, or included components.

No Bots, Just Experts

Questions about this product? Free pre-sales support from a senior specialist — product questions, compatibility checks, BOM quotes, price confirmation — typically answered within one business day. Need camera placement or system design work? Engineering time is $175 per hour (qty 1 = 1 hour). Hardware buyers get up to one hour ($175) credited back on their order.

Get Free Pre-Sales Support Buy Design Hours ($175/hr)
Description

Panduit LCAN250-38-X Concise Descriptor

Overview

The Panduit LCAN250-38-X is a single-hole, 250 Kcmil copper compression lug designed for terminating large gauge conductors in power distribution and industrial control applications. It ensures a reliable, low-resistance connection essential for preventing power loss and ensuring system stability in demanding environments. This lug is specified for use with 250 Kcmil stranded copper conductors.

Compatibility

This lug is engineered for use with 250 Kcmil stranded copper conductors. It is compatible with standard hydraulic crimping tools that accept 0.441" (11.2 mm) hex dies, such as Panduit CT-940CH, CT-960CH, and CT-980CH, or equivalent tools from other manufacturers. Ensure your crimping tool and die set are rated for 250 Kcmil conductors and the lug's dimensions.

Installation Notes

For optimal performance and safety, the Panduit LCAN250-38-X requires a specific crimping die and tool. A 0.441" (11.2 mm) hex die is specified. The lug should be crimped firmly to ensure electrical continuity and mechanical integrity. Torque specifications for the mounting hole should adhere to the equipment manufacturer's guidelines, typically ranging from 30 to 45 ft-lbs for a 3/8" stud.

What's in the Box

  • 1x Panduit LCAN250-38-X Copper Compression Lug
Expert Analysis
Specifications
Manufacturer Part Number: LCAN250-38-x
Manufacturer: Panduit Corp
Series: Pan-Lug
Terminal Type: Rectangular Tongue
Stud Tab Size: 3/8 Stud
Terminal Style: Single Stud Hole
Tab Thickness: 0.150" (3.81mm)
Length Overall: 2.550" (64.77mm)
Width Outer Edges: 0.770" (19.56mm)
Mounting Type: Free Hanging (In-Line)
Termination: Crimp, Barrel
Wire Gauge: 250 MCM (kcmil)
Insulation: Non-Insulated
Color: Yellow
Q&A
Reviews
Product Video

Panduit CU COMPRESSION LUG 1 HOLE 250 K - LCAN250-38-X

$190.99
Add to Cart
