Panduit QCRBCCB0001F010 Cat6 UTP Copper Trunk Cassette 10ft
Overview
The Panduit QCRBCCB0001F010 is a Category 6 UTP copper trunk cassette designed for structured cabling deployments in enterprise network infrastructure environments — data centers, telecommunications rooms, and high-density horizontal distribution frames where speed of patching and cable management density matter. At 10 feet, this cassette format lets you deploy pre-terminated copper trunk segments without field-terminating individual runs, eliminating the variability and labor cost of punch-down termination on the floor.
This cassette supports 1 Gbps data rates across a 250 MHz bandwidth envelope, meeting the full Category 6 performance specification under TIA-568-C.2 and ISO/IEC 11801. If your infrastructure standard requires documented compliance with those frameworks — and most enterprise IT and telecom room deployments do — the QCRBCCB0001F010 checks those boxes without qualification work on your end.
Key Features
- Category 6 / 250 MHz Bandwidth: The 250 MHz headroom of Cat6 is the reason this cassette supports 1 Gbps reliably rather than theoretically. Deployments running Gigabit switching fabric — which is the baseline for virtually every enterprise access layer today — get full wire-speed performance without the frequency-ceiling compromises of Cat5e infrastructure.
- 1 Gbps Data Rate: Sufficient for current access-layer and horizontal cabling requirements in most commercial buildings and data center edge zones. If you are planning 10GbE to the desktop or high-density server rows requiring 10GBASE-T, evaluate whether Cat6A trunk cassettes better fit your roadmap — Cat6 at 10Gbps is distance-limited and performance-marginal over longer runs.
- UTP (Unshielded) Construction: UTP is the correct choice for most commercial office and enterprise networking environments where EMI exposure is not a design constraint. It simplifies termination, reduces cassette bulk, and eliminates the grounding continuity requirements that come with shielded (STP/FTP) systems. If you are running near high-voltage industrial equipment or in environments with significant RF interference, evaluate shielded alternatives from the Panduit structured cabling line.
- TIA-568-C.2 and ISO/IEC 11801 Compliance: These are the two governing standards for commercial building telecommunications cabling in North America and internationally, respectively. Compliance means the cassette has been tested to defined insertion loss, return loss, NEXT, and ELFEXT parameters — not just labeled. This matters when your cabling installation is being commissioned against a documented standard or when warranty claims on the infrastructure require standards-conforming components.
- UL Listed: UL listing verifies that the product has been independently evaluated for electrical safety and fire performance. In most commercial construction projects and data center fit-outs, UL listing on cabling infrastructure is a code or insurance requirement, not optional.
- Pre-Terminated Trunk Cassette Format: Cassette-based trunk systems reduce moves, adds, and changes (MACs) from a termination task to a connector-swap operation. In structured cabling environments with frequent patching activity — enterprise MACs, lab reconfigurations, co-location cross-connects — the cassette format pays for itself in labor reduction over the infrastructure lifecycle.
- Blue Color Coding: Blue jacket and connector color coding is the TIA-606-B standard designation for horizontal cabling. Using correctly color-coded infrastructure reduces mis-patching errors in high-density frames and simplifies administration for NOC and facilities teams working under time pressure.
- 10-Foot Length: The 10-foot cassette span is suited for within-rack or adjacent-rack trunk runs — top-of-rack to patch panel, row interconnect within a single cage, or short-haul horizontal distribution. For longer runs across a floor or between separate telecom rooms, evaluate longer trunk assemblies from the same product family.
Integration and Compatibility
The QCRBCCB0001F010 is designed to integrate with Panduit's QuickNet trunk cabling system. Cassette-based trunk infrastructure is compatible with standard 1U and 2U patch panel frames that accept snap-in cassette modules — verify your panel frame accepts Panduit QuickNet cassette form factor before ordering. The Cat6 UTP electrical specification is backward compatible with Cat5e infrastructure and forward compatible with most Cat6-rated active equipment. Because this is a passive copper cassette, there are no firmware, driver, or VMS dependencies — it connects to any standard RJ-45 port.
For network switches in the same rack or row, pairing with a PoE-capable network switch in the distribution layer allows downstream IP devices to be powered over the same Cat6 horizontal runs this cassette supports, without any additional cabling infrastructure.
Frequently Asked Questions
Q: What cabling standard does the QCRBCCB0001F010 comply with?
A: The QCRBCCB0001F010 meets TIA-568-C.2 (North American commercial building cabling standard) and ISO/IEC 11801 (international cabling standard for generic premises). It is also UL Listed for electrical safety compliance.
Q: What data rate does this Cat6 cassette support?
A: The QCRBCCB0001F010 supports 1 Gbps data rates over its 250 MHz bandwidth envelope, consistent with the Category 6 specification under TIA-568-C.2.
Q: Is this cassette shielded?
A: No. The QCRBCCB0001F010 uses UTP (Unshielded Twisted Pair) construction. It is appropriate for standard commercial and enterprise environments without significant EMI. If shielding is required, evaluate shielded Cat6 alternatives.
Q: What is the cable length on this trunk cassette?
A: The QCRBCCB0001F010 is a 10-foot (approximately 3-meter) trunk cassette, suited for within-rack or short adjacent-rack runs.
Q: What panel system does this cassette work with?
A: This cassette is part of Panduit's QuickNet trunk cabling system and is designed to integrate with compatible QuickNet patch panel frames. Confirm frame compatibility before ordering if you are integrating into an existing non-Panduit infrastructure.
Q: Can I use this cassette with 10GbE equipment?
A: The QCRBCCB0001F010 is rated for Category 6 / 1 Gbps performance. While Cat6 can theoretically support 10GBASE-T at very short distances, it is not the recommended media for 10GbE deployments — Cat6A is the appropriate standard for reliable 10 Gbps copper cabling.
The QCRBCCB0001F010 is a Cat6 UTP copper trunk cassette operating at 250 MHz — that bandwidth ceiling is what separates it from Cat5e and determines where it fits in your infrastructure plan. If your access layer is running standard Gigabit switching and you need pre-terminated trunk segments for a data center or telecom room build-out, this cassette format is the right operational model: swap cassettes instead of re-terminating, document to TIA-568-C.2, and move on.
Technical Highlights:
- 250 MHz / Cat6 Rating: Supports the full Category 6 bandwidth specification, delivering 1 Gbps with margin. At 250 MHz, you have roughly double the frequency headroom of Cat5e — meaningful for signal integrity in dense panel environments with cross-talk exposure.
- TIA-568-C.2 and ISO/IEC 11801 Compliance: Both standards require tested performance at defined NEXT, return loss, and insertion loss parameters — not just labeling. This covers North American commissioning requirements (TIA) and international specifications (ISO/IEC) in a single cassette, which simplifies procurement for multi-site enterprise deployments.
- UL Listed Construction: UL listing is a hard requirement in most commercial data center fit-outs and building code jurisdictions. Having it on the cassette itself, not just the broader system, avoids compliance gaps when inspectors pull component-level documentation.
Deployment Considerations:
- The 10-foot length positions this cassette for within-rack or tight adjacent-rack applications. Map your actual trunk span before ordering — if your distribution frame is more than a few feet from the termination point, you will need a longer assembly from the same family rather than daisy-chaining cassettes.
- UTP shielding is appropriate for standard commercial environments, but confirm your telecom room or data hall does not have documented EMI sources (UPS systems, motor-driven HVAC in close proximity, high-density power distribution). If EMI is a concern, the correct answer is shielded Cat6 or Cat6A STP — not UTP with additional bonding attempts.
The QCRBCCB0001F010 is the right spec for enterprise horizontal cabling and telecom room trunk segments where the active layer runs Gigabit, the infrastructure standard is TIA-568-C.2, and the operational model prioritizes cassette-swap MACs over field-terminated runs. It is not the cassette to specify if 10GbE to the desktop is on your 18-month roadmap — plan for Cat6A trunks in that scenario from the start.
